AUTO-CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-257

34

FUSIBLE
LINK

POWER
DISTRIBUTION
SYSTEM

IGNITION
SWITCH (IG1)

ETACS-
ECU

IG1
RELAY

STOPLIGHT
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·SHIFT LOCK MECHANISM
·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
·STOPLIGHT

AUTO-CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-258

AUTO-CRUISE CONTROL SYSTEM (CONTINUED)

HALL IC

ENGINE
CONTROL
MODULE

ACCELERATOR PEDAL
POSITION SENSOR

THROTTLE
ACTUATOR
CONTROL
MOTOR

THROTTLE
BODY
ASSEMBLY

HALL IC

(SUB)

HALL IC

(MAIN)

HALL IC

(SUB)

(MAIN)

AUTO-CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-259

CLOCK
SPRING

COMBINATION
METER

RHEOSTAT

ENGINE
CONTROL
MODULE

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

AUTO-CRUISE
CONTROL
SWITCH

ETACS-
ECU

CPU

INTERFACE
CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID
 CONTROL SYSTEM (ASC)
·CLOCK
·ELECTRIC CONTROLLED
 AWD
·INVECS-II 6A/T
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT

THEFT-ALARM
SYSTEM

AUTO-CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-260

AUTO-CRUISE CONTROL SYSTEM (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

ENGINE
CONTROL
MODULE

(FUSE     )

5

ETACS-ECU
