Mitsubishi Outlander XL. Manual - part 130

SPARE CONNECTOR (FOR REAR DISPLAY)

CIRCUIT DIAGRAMS

90-217

ACC
RELAY 2

FUSIBLE
LINK

37

ETACS-
ECU

IGNITION
SWITCH (ACC)

·HEATED
 DOOR
 MIRROR
·REAR
 WINDOW
 DEFOGGER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

REMOTE
CONTROLLED
MIRROR

SPARE CONNECTOR (FOR REAR DISPLAY)

CIRCUIT DIAGRAMS

90-218

SPARE CONNECTOR (FOR REAR DISPLAY) (CONTINUED)

COMBINATION
METER

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

CPU

ETACS-ECU

(FUSE    )

9

RHEOSTAT

TONE
ALARM

INTERFACE
CIRCUIT

FRONT SIDE

SPARE CONNECTOR
(FOR REAR DISPLAY)

:

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID
 CONTROL SYSTEM
 (ASC)
·AUDIO SYSTEM
·AUTO-CRUISE
 CONTROL SYSTEM
·CLOCK
·ELECTRIC
 CONTROLLED AWD
·HANDS FREE
 SYSTEM

·AIR CONDITIONING
 SYSTEM
·ELECTRIC
 CONTROLLED 4WD
·INVECS-II 6A/T
·TURN-SIGNAL
 LIGHT AND
 HAZARD WARNING
 LIGHT

:

NOTE

·INVECS-II 6A/T
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·TURN-SIGNAL
 LIGHT AND
 HAZARD WARNING
 LIGHT

SPARE CONNECTOR (FOR REAR DISPLAY)

CIRCUIT DIAGRAMS

90-219

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ETACS-ECU

(FUSE    )

5

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

ANTI-LOCK BRAKING SYSTEM (ABS)

CIRCUIT DIAGRAMS

90-220

ANTI-LOCK BRAKING SYSTEM (ABS)

FUSIBLE
LINK

27

FUSIBLE
LINK

26

ETACS-ECU

STOPLIGHT
SWITCH

SOLENOID VALVE
POWER SUPPLY

MOTOR POWER
SUPPLY

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

·SHIFT LOCK MECHANISM
·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
·STOPLIGHT
