GENERAL INFORMATION
M23300000001USA0000010000
The MacPherson strut type suspension is adopted.
MAIN FEATURES
｠
The wheel tread is enlarged to improve cornering
ability.
｠
The roll center height is reviewed with regarding the
vehicle specifications to improve the steering ability.
｠
Increasing of the suspension stroke enables to
improve the road holding quality, and secures good
adhesion even on bumpy/rough roads to reduce
shocks received when the vehicle negotiates
bumps.
｠
The fully flattened crossmember improves the left/
right direction rigidity of installation points of the
lower arms for high steering ability.
｠
Tuning of the lower arm bushes improves the
steering ability and riding comfort.
｠
The stabilizer bar is joined to the strut for high
efficiency to secure the optimum rolling rigidity, and
improves the steering ability.
｠
Total tuning of struts, springs, and bump rubbers
improves the steering ability and riding comfort.
CONSTRUCTION DIAGRAM
ZC6008360000
Stabilizer bar
Coil spring
Shock absorber
Stabilizer link
Lower arm
Front axle crossmember
(Flat crossmember)
SPECIFICATIONS
SUSPENSION SYSTEM
ITEM
SPECIFICATION
Suspension type
MacPherson strut with coil spring
33-2
FRONT SUSPENSION
GENERAL INFORMATION
