Mitsubishi Outlander XL. Manual - part 114
WINDSHIELD WIPER AND WASHER
CIRCUIT DIAGRAMS
90-153
IGNITION
SWITCH (ACC)
WINDSHIELD
WIPER
MOTOR
ACC
RELAY3
WINDSHIELD
WIPER
AUTOMATIC
STOP RELAY
WINDSHIELD
WASHER
RELAY
REAR
WINDOW
WASHER
RELAY
WASHER
MOTOR
CIRCUIT
BRAKER
WINDSHIELD
WIPER SPEED
SWITCHING
RELAY
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE
: ·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS) AND
ACTIVE SKID CONTROL SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·CHAGING SYSTEM
·CONTROLLER AREA NETWORK (CAN)
·DOME LIGHT, LUGGAGE COMPARTMENT
LIGHT AND IGNITION KEY HOLE
ILLUMINATION LIGHT
·HEADLIGHT AUTOMATIC LEVELING
SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL
RESTRAINT
SYSTEM (SRS)
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
MONITORING SYSTEM
(TPMS)
