CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-125

DOOR
LOCK
RELAY

PASSENGER'S
DOOR
UNLOCK
RELAY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

LIFTGATE
LOCK
RELAY

REAR
DOOR
LOCK
ACTUATOR
(LH)

REAR
DOOR
LOCK
ACTUATOR
(RH)

LIFTGATE
LOCK
ACTUATOR

KEY
REMINDER
SWITCH
WHEN
REMOVING
KEY: ON

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-126

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

IGNITION
SWITCH (IG1)

ETACS-ECU

FUSIBLE
LINK

34

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

IG1
RELAY

TRANSMISSION
RANGE SWITCH

DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT

TRANSMISSION
CONTROL
MODULE

·SHIFT LOCK MECHANISM
·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
·STOP LIGHT

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-127

FRONT DOOR
SWITCH (RH)

FRONT DOOR
SWITCH (LH)

REAR DOOR
SWITCH (LH)

REAR DOOR
SWITCH (RH)

LIFTGATE
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-128

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

KEYLESS
OPERATION
KEY

RECEIVER ANTENNA MODULE

KEYLESS
ENTRY
RECEIVER

KOS-ECU

<VEHICLES WITH KOS>

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

IG1
RELAY

FUSIBLE
LINK

36

ENGINE
COMPARTMENT

RELAY BOX

ETACS-ECU
