Mitsubishi Outlander XL. Manual - part 98

DOME LIGHT, LUGGAGE COMPARTMENT LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

CIRCUIT DIAGRAMS

90-89

COMBINATION
METER

CPU

CAN
TRANSCEIVER
CIRCUIT

LCD

CAN DRIVE CIRCUIT

INTERFACE CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

(EACH DOOR)

DOME LIGHT, LUGGAGE COMPARTMENT LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

CIRCUIT DIAGRAMS

90-90

DOME LIGHT, LUGGAGE COMPARTMENT LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT
(CONTINUED)

IGNITION
SWITCH (IG1)

ETACS-
ECU

FUSIBLE
LINK

34

IG1
RELAY

<VEHICLES WITHOUT KOS>

KEYLESS
ENTRY
RECEIVER

KEYLESS
ENTRY
TRANSMITTER

WIRELESS CONTROL MODULE

(FUSE     )

30

RELAY BOX

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS) AND
 ACTIVE SKID CONTROL SYSTEM (ASC)
·AUTO-CRUISE CONTROL SYSTEM
·BRAKE WARNING LIGHT
·CHARGING SYSTEM
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOOR AJAR WARNING TONE ALARM
·ELECTRIC CONTROLLED AWD
·FOG LIGHT
·FUEL WARNING LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC LEVELING SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
·INVECS-II 6A/T
·METER AND GAUGE
·MFI SYSTEM
·OIL PRESSURE WARNING LIGHT
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

:

NOTE

DOME LIGHT, LUGGAGE COMPARTMENT LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

CIRCUIT DIAGRAMS

90-91

<VEHICLES WITH KOS>

KOS-ECU

KEYLESS
OPERATION
KEY

RECEIVER ANTENNA MODULE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

KEYLESS
ENTRY
RECEIVER

:  ·AIR CONDITIONING SYSTEM

·BRAKE WARNING LIGHT
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·FOG LIGHT
·FUEL WARNING LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER TONE ALARM
·METER AND GAUGE
·OIL PRESSURE WARNING LIGHT
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·TAILLIGHT, POSITION LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

GLOVE BOX LIGHT

CIRCUIT DIAGRAMS

90-92

GLOVE BOX LIGHT

FUSIBLE
LINK

36

IG1
RELAY

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

TAILLIGHT
CONTROL
CIRCUIT

GLOVE
BOX LIGHT

COLUMN
SWITCH

LIGHTING
SWITCH

COLUMN-ECU

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

(TAIL)

POWER
DISTRIBUTION
SYSTEM

ETACS-ECU

RELAY BOX

ENGINE
COMPARTMENT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET     PU : PURPLE

POWER
WINDOWS

:

NOTE

:

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FUEL WARNING LIGHT
·IGNITION KEY
 REMINDER TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·METER AND GAUGE
·OIL PRESSURE WARNING LIGHT
·POWER WINDOWS
·SEAT BELT WARNING TONE ALARM
·SUNROOF
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)

·AIR
 CONDITIONING
 SYSTEM
·ANTI-LOCK
 BRAKING
 SYSTEM (ABS)
·ANTI-LOCK
 BRAKING
 SYSTEM (ABS)
 AND
 ACTIVE SKID
 CONTROL
 SYSTEM (ASC)
·CENTRAL DOOR
 LOCKING
 SYSTEM
·CONTROLLER
 AREA
 NETWORK (CAN)
·DOME LIGHT,
 LUGGAGE
 COMPARTMENT
 LIGHT AND
 IGNITION KEY
 HOLE
 ILLUMINATION
 LIGHT
·HEADLIGHT
 AUTOMATIC
 LEVELING
 SYSTEM
·HEATED DOOR
 MIRROR
·HEATED SEAT
·IMMOBILIZER
 SYSTEM
·INVECS-II 6A/T
·KEYLESS
 OPERATING
 SYSTEM (KOS)
·POWER
 WINDOWS
·REAR WINDOW
 DEFOGGER
·SEAT BELT
 WARNING
 TONE ALARM
·SHIFT LOCK
 MECHANISM
·SUNROOF
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)
·THEFT-ALARM
 SYSTEM
·TIRE PRESSURE
 MONITORING
 SYSTEM (TPMS)

HEATED
SEAT
