Mitsubishi Outlander XL. Manual - part 92

INVECS-II 6A/T

CIRCUIT DIAGRAMS

90-65

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

FRONT SIDE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

TRANSMISSION
CONTROL
MODULE

HEADLIGHT <HALOGEN TYPE>

CIRCUIT DIAGRAMS

90-66

HEADLIGHT <HALOGEN TYPE>

RELAY BOX

ENGINE
COMPARTMENT

FUSIBLE
LINK

36

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
ASSEMBLY
(RH)

HEADLIGHT
(HIGH: RH)

HEADLIGHT
(HIGH: LH)

HEADLIGHT
RELAY
(LOW)

HEADLIGHT
RELAY
(HIGH)

FEELD EFFECT
TRANSISTOR

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS)
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE SKID
 CONTROL SYSTEM (ASC)
·CENTRAL DOOR LOCKING
 SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEADLIGHT AUTOMATIC
 LEVELING SYSTEM

·HEATED DOOR MIRROR
·HEATED SEAT
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM
 (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)

NOTE

:

HEADLIGHT <HALOGEN TYPE>

CIRCUIT DIAGRAMS

90-67

RELAY
BOX

ENGINE
COMPARTMENT

(HEAD)

(TAIL)

ETACS-ECU

FUSIBLE
LINK

36

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

IG1
RELAY

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

COLUMN
SWITCH

COLUMN-ECU

LIGHTING
SWITCH

DIMMER
SWITCH

(DIMMER)

(PASSING)

HEADLIGHT AND FAN
BACKUP CIRCUIT

POWER
DISTRIBUTION
SYSTEM

PASSING
SWITCH

POWER
WINDOWS

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FUEL WARNING LIGHT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·METER AND GAUGE
·OIL PRESSURE
 WARNING LIGHT
·POWER WINDOWS
·SEAT BELT WARNING
 TONE ALARM
·SUNROOF
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM
 (TPMS)

HEADLIGHT <HALOGEN TYPE>

CIRCUIT DIAGRAMS

90-68

HEADLIGHT <HALOGEN TYPE> (CONTINUED)

ETACS-ECU

INTERFACE CIRCUIT

CAN DRIVE CIRCUIT

DATA LINK
CONNECTOR

FRONT SIDE

34

FUSIBLE
LINK

FRONT DOOR
SWITCH (LH)
