Mitsubishi Outlander XL. Manual - part 91

INVECS-II 6A/T

CIRCUIT DIAGRAMS

90-61

LOW CLUTCH
LINEAR
SOLENOID
VALVE

LINE
PRESSURE
LINEAR
SOLENOID
VALVE

LOW-
REVERSE
BRAKE SHIFT
SOLENOID
VALVE

2-6 BRAKE
LINEAR
SOLENOID
VALVE

3-5 REVERSE
CLUTCH
LINEAR
SOLENOID
VALVE

HIGH CLUTCH
LINEAR
SOLENOID
VALVE

LOW CLUTCH
SHIFT
SOLENOID
VALVE

A/T
CONTROL
SOLENOID
VALVE
ASSEMBLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

INVECS-II 6A/T

CIRCUIT DIAGRAMS

90-62

INVECS-II 6A/T (CONTINUED)

PADDLE
SHIFT
SWITCH

SHIFT
SWITCH

SPORT
MODE

AUTO
MODE

SELECT
SWITCH

SHIFT
SWITCH
ASSEMBLY

<VEHICLES WITH
 PADDLE SHIFT>

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE SKID
 CONTROL SYSTEM (ASC)
·ELECTRIC CONTROLLED 4WD
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT

TRANSMISSION
CONTROL
MODULE

INVECS-II 6A/T

CIRCUIT DIAGRAMS

90-63

ETACS-ECU

ETACS-ECU

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

TRANSCEIVER
CIRCUIT

LCD

·A/T POSITION
·A/T TEMPERATURE
·A/T FAILURE

COMBINATION METER

RHEOSTAT

ETACS-ECU
(FUSE      )

12

RELAY BOX
(FUSE      )

30

CPU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID CONTROL
 SYSTEM (ASC)
·AUDIO SYSTEM
·AUTO-CRUISE CONTROL
 SYSTEM

·CLOCK

·ELECTRIC CONTROLLED
 AWD
·HANDS FREE SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT

THEFT-ALARM
SYSTEM

INVECS-II 6A/T

CIRCUIT DIAGRAMS

90-64

INVECS-II 6A/T (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

ENGINE
CONTROL
MODULE

INPUT SIGNAL

·ACCELERATOR PEDAL
 POSOTION SENSOR
·CRANKSHAFT POSITION
 SENSOR

ETACS-ECU

(FUSE     )

5

ETACS-ECU
