When  service  procedures  require  removing  rear
suspension, fuel tank and spare tire, place additional weight
on  the  rear  end  of  vehicle,  or  anchor  vehicle  to  hoist  to
prevent tipping when the center of gravity changes.

ZC501945

Notch

Notch

0000

GENERAL <BODY AND CHASSIS>

00-45

TOWING AND HOISTING

GENERAL DATA AND SPECIFICATIONS

M10001000009USA0000010000

<Except vehicles for CANADA>

ZC5019470000

5
2

9

7

4
1

8

3

6

Item

CW6W
XLSYL2M/7M

XLHYL2M/7M

XLSYZL2M/7M XLHYZL2M/7M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

1,680 (66.1)
<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,615 (3,560)

1,635 (3,604)

1,680 (3,703)

1,700 (3,747)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,280 (2,822)

Seating capacity

5

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

00-46

GENERAL <BODY AND CHASSIS>

GENERAL DATA AND SPECIFICATIONS

Item

CW6W
XLMYL2M

XLXYL2M/7M

XLXYZL2M/7M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles

 without

roof rail>
1,720 (67.7)
<Vehicles  with  roof
rail>

1,720 (67.7)
<Vehicles  with  roof
rail>

1,680 (66.1)
<Vehicles

 without

roof rail>
1,720 (67.7)
<Vehicles  with  roof
rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,675 (3,692)

1,670 (3,681)

1,735 (3,825)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,280 (2,822)

Seating capacity

7

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

<Vehicles for CANADA>

ZC5019470000

5
2

9

7

4
1

8

3

6

GENERAL <BODY AND CHASSIS>

00-47

GENERAL DATA AND SPECIFICATIONS

Item

CW6W
XLSYL3M

XLSYZL3M

XLXYL3M

XLXYZL3M

Vehicle
dimension mm
(in)

Overall length

1 4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

4,640 (182.7)

Overall width

2 1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

1,800 (70.9)

Overall

 height

(unladen)

3 1,680 (66.1)

<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

1,680 (66.1)
<Vehicles
without

 roof

rail>
1,720 (67.7)
<Vehicles  with
roof rail>

1,720 (67.7)
<Vehicles  with
roof rail>

Wheelbase

4 2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

2,670 (105.1)

Tread-front

5 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Tread-rear

6 1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

1,540 (60.6)

Overhang-front

7 965 (38.0)

965 (38.0)

965 (38.0)

965 (38.0)

Overhang-rear

8 1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

1,005 (39.6)

Ground clearance 9 215 (8.5)

215 (8.5)

215 (8.5)

215 (8.5)

Vehicle weight
kg (lb)

Curb weight

1,615 (3,560)

1,680 (3,703)

1,670 (3,681)

1,735 (3,825)

Gross  vehicle  weight
rating

2,300 (5,071)

2,350 (5,181)

2,300 (5,071)

2,350 (5,181)

Gross  axle  weight
rating-front

1,090 (2,403)

Gross  axle  weight
rating-rear

1,100 (2,425)

Seating capacity

5

7

Engine

Model No.

6B31

Piston displacement

3.0 L

Transaxle

Model No.

F6AJA

W6AJA

F6AJA

W6AJA

Type

6-speed automatic

Fuel system

Fuel supply system

Multiport fuel injection

TIGHTENING TORQUE

M10001000011USA0000010000

Each torque value in the table is a standard value for
tightening under the following conditions.

1.

Bolts, nuts and washers are all made of steel and
plated with zinc.

2.

The threads and bearing surface of bolts and nuts
are all in dry condition.

The values in the table are not applicable:

1.

If toothed washers are inserted.

2.

If plastic parts are fastened.

3.

If bolts are tightened to plastic or die-cast inserted
nuts.

4.

If self-tapping screws or self-locking nuts are used.



00-48

GENERAL <BODY AND CHASSIS>

TIGHTENING TORQUE
