Mitsubishi Outlander XL. Manual - part 30

No.

Part name

Material

Abbreviat
ion

 of

material

Heat-
resistant
temperat
ure  [°C  (°
F)]

1

Radiator grille

Acrylonitrile butadiene styrene

ABS

80 (176)

2

Door mirror

3

Rear roof garnish

4

Liftgate spoiler

5

Roof rack cover front

6

Roof rack cover center

7

Roof rack cover rear

8

Roof antenna base center

Acrylonitrile ethylene styrene

AES

80 (176)

9

Fog light bezel

Acrylonitrile styrene acrylate

ASA

80 (176)

10

Headlight

Polycarbonate

PC

120 (248)

11

Front door outside handle

Polycarbonate+Polyethylene
terephthalate

PC+PET

120 (248)

12

Rear door outside handle

13

Front splash shield

Polyethylene

PE

100 (212)

14

Rear splash shield

High density polyethylene

PE-HD
(HDPE)

70  -  90
(158 - 194)

15

Inside rear view mirror

Polypropylene

PP

80 (176)

16

Lower quarter trim

17

Upper liftgate trim

18

Liftgate trim side

19

Liftgate trim

20

Lower liftgate trim

21

Rear scuff plate

22

Front scuff plate

23

Rear end trim

24

Cowl side trim

25

Front bumper face

Rubber denatured polypropylene

PP+E/P

80 (176)

26

Front deck garnish

27

Rear bumper face

28

Rear corner bumper

29

Side air dam

Talc

 filled

 rubber

 modified

polypropylene (20%)

PP+E/P-
TD20

110 (230)

30

Front door trim

Talc filled polypropylene (10%)

PP-TD10
(PPF)

110  -  120
(230 - 248)

31

Rear door trim

32

Lower center pillar trim

SYNTHETIC-RESIN PARTS

5-3

LOCATION OF SYNTHETIC-RESIN PARTS

No.

Part name

Material

Abbreviat
ion

 of

material

Heat-
resistant
temperat
ure  [°C  (°
F)]

33

Front pillar trim

Talc filled polypropylene (20%)

PP-TD20
(PPF)

120  -  130
(248 - 266)

34

Upper center pillar trim

35

Upper quarter trim

36

Floor console rear

37

Floor console front

38

Instrument panel

NOTE:

｠

If the material symbols designated by the ISO differ
from the old symbols, both are given, with the old
symboling enclosed in brackets.
ISO: International Standardization Organization.

｠

A slash (/) in the material symbol indicates that two
different materials make two-layer construction. A
plus  sign  (+)  indicates  that  the  two  different
materials mix each other.

｠

The indicated heat-resistant temperature for parts
which  are  composed  of  two  or  more  types  of
material is the value for the material with the lowest
heat-resistant temperature.

｠

The material symbols for synthetic-resin parts are
embossed on the parts in hidden places.

5-4

SYNTHETIC-RESIN PARTS

LOCATION OF SYNTHETIC-RESIN PARTS

GROUP 6

BODY COLOR

CONTENTS

BODY COLOR CODE..................

6-2

BODY COLOR CHARTS................

6-2

BODY COLORING....................

6-3

RADIATOR GRILLE..................

6-3

WHEELHOUSE.......................

6-4

6-1

BODY COLOR CODE

M40600000010USA0000010000

ZB500428

Body color code

0000

Body color code is stamped on the name plate, which is attached
on the underside of the center pillar (right side).

BODY COLOR CHARTS

M40600000020USA0000010002

Color

Color code

Color number

Color name (Previous name)

Composition  of
film

SILVER

A31

CMA10031

Cool Silver Metallic

Metallic

MEDIUM
PURPLISH GRAY

A39

CMA10039

Medium Purplish Gray Mica

Metallic

 +

Interferenced
Pearl

GREENISH
SILVER

A86

CMA10086

Aqua Metallic

Metallic

 +

Interferenced
Pearl

DEEP BLUE

T65

CMT10065

Deep Blue Mica

Interferenced
Pearl

BEIGE

S18

CMS10018

Beige Metallic (Fraser Beige)

Metallic

 +

Interferenced
Pearl

BLACK

X42

AC11342

Black Mica (Amethyst Black)

Interferenced
Pearl

WHITE

W13

CMW10013

White Pearl

Pearl

RED

P23

CMP10023

Red Solid

Solid

NOTE:

For painting, inner panel colors should be

similar to the outer panel colors.

6-2

BODY COLOR

BODY COLOR CODE
