MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-795

Inspection procedure 24: Ignition switch-ST system and starter relay system

M

1

1

2

3
4

5 6

1 2 3 4

7

8

9 10

71 72 73 74 75 76 77 78 79 80 81 82

83 84 85 86 87 88 89 90 91 92 93 94

95 96 97 98 99

100 101 102 103 104

112 113 114

109

108

107

110 111

115 116

106

105

118

117

7

3

8

1

4

9

13 14

16

15

10 11 12

17 18 19

2

5 6

1

6

4

5

9

8

10 11

13

15

14

12

16

7

2 3

1 2 3
4 5 6

AK900381

1

10 111213 14 1516 17 1819 20

2 3 4

5 6 7 8 9

1

1

2

3 4 5 6 7 8 9 10 11 12 13 14 15 16

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64

1

D

Ds

N

R

P

OFF

ON

1

OFF

ON

10

106

6

B-11

105

15

7

C-304

ENGINE
CONTROL
MODULE

A-13

B-10

ETACS-ECU

7

IG2

ST

LOCK

ACC

IG1

5

B-114

(MU801211)

B-110

MU802355

STARTER

STARTER
RELAY

TRANSMISSION
RANGE
SWITCH

B-113

A-27X

6

3

1

4

2

BLA

CK-RED

RED-WHITE

RED-WHITE

WHITE

GREEN

GREEN

ORANGE

LIGHT

GREEN

12

11

C-315

MU801890

C-210

IGNITION SWITCH

STARTING SYSTEM CIRCUIT

AB

BATTERY

FUSIBLE LINK 24

1

GREEN

B-23

MU802653

1

BLA

CK

BLA

CK

BLA

CK

BLA

CK-RED

BLA

CK-RED

BLA

CK-RED

BLA

CK-RED

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-796

.

CIRCUIT OPERATION

• If the selector lever is moved to "P" or "N" range

and the ignition switch is turned to "START" posi-
tion, battery positive voltage is supplied to starter
relay coil. With this, the starter relay turns "ON"
the battery positive voltage is supplied to the
starter motor (terminal No. 1) from the battery.

.

COMMENT

• Faulty starting system and the related circuit are

suspected to be the causes.

.

AK704087AB

Connector: A-13

A-13

AK704315

AB

Connector: A-27X

A-27X

Starter relay

AK704151AB

Connector: B-10, B-11

B-10 (GR)

B-11 (GR)

AK704316

AB

Connectors: B-23, B-113 and B-114

B-114 (B)

B-113

B-23 (B)

AK704317

AB

Connector: B-110

B-110 (B)

AK900601

Connector: C-210

C-210

AB

AK700445AB

ETACS-ECU

C-315

Connectors: C-304, C-315

C-304

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-797

TROUBLESHOOTING HINTS (The most
likely causes for this case:)

• Battery failed

• Malfunction of the starter motor relay.

• Malfunction of the starter motor.

• Open or shorted starting system circuit, harness

damage, or connector damage.

• Malfunction of the transmission range switch.

• Malfunction of the ECM

DIAGNOSIS

Required Special Tools:

• MB991958: Scan Tool (M.U.T.-III Sub Assembly)

• MB991824: V.C.I.

• MB991827: USB Cable

• MB991910: Main Harness A

STEP 1. Using scan tool MB991958, check data list item 79:
Cranking signal.

CAUTION

To prevent damage to scan tool MB991958, always turn the
ignition switch to the "LOCK" (OFF) position before con-
necting or disconnecting scan tool MB991958.
(1) Connect scan tool MB991958 to the data link connector
(2) Turn the ignition switch to the "ON" position.
(3) Set scan tool MB991958 to the data reading mode for item

79, Cranking Signal.

• When the engine is stopped, "OFF" will be displayed.

• When the engine is cranked, "ON" will be displayed.

(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the operating properly?

YES : Go to Step 9.
NO :  Go to Step 2.

STEP 2. Check harness connector C-304, C-315 at
ETACS-ECU connector for damage.
Q: Is the connector in good condition?

YES : Go to Step 3.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. Then confirm that the

malfunction symptom is eliminated.

AK700568AB

MB991824

MB991827

MB991910

Data link
connector

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-798

STEP 3. Measure the ignition switch-ST signal voltage at
ETACS-ECU harness side connector C-315.
(1) Disconnect the connector C-315 and measure at the

harness side.

(2) Turn the ignition switch to the "START" position.
(3) Measure the voltage between terminal No. 7 and ground.

• Voltage should be battery positive voltage

(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is battery positive voltage (approximately 12 volts)

present?
YES :
Go to Step 6.
NO :  Go to Step 4.

STEP 4. Check harness connector C-210 ignition switch
connector for damage.
Q: Is the connector in good condition?

YES : Go to Step 5.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. Then confirm that the

malfunction symptom is eliminated.

STEP 5. Check the ignition switch
Refer to GROUP 54A, Ignition Switch

− Inspection − Ignition

Switch Continuity Check

P.54A-26

.

Q: Are there any abnormalities?

YES : Replace the Ignition Switch. Then confirm that the

malfunction symptom is eliminated.

NO :  Repair harness wire between Ignition Switch

connector C-210 (terminal No. 5) and ETACS-ECU
connector C-315 (terminal No. 7) because of open
circuit or short circuit to ground. Then confirm that the
malfunction symptom is eliminated

STEP 6. Check for harness damage between ignition
switch connector C-210 (terminal No. 5) and ETACS-ECU
connector C-315 (terminal No. 7).
Q: Is the harness wire in good condition?

YES : Go to Step 7.
NO :  Repair it. Then confirm that the malfunction symptom

is eliminated.

12

6

11

2

5

10

19 18

16

17

9 8 7

15 14 13

1

4 3

AK704318

C-315 harness
connector:
component side

AB
