DIAGNOSIS TSB Revision ACTIVE STABILITY CONTROL SYSTEM (ASC) 35C-67 STEP 10. Check whether the DTC is reset. NOTE: The ABS warning light does not turn OFF in some Q: Is DTC C1014 set? YES : Return to Step 1. DTC C101F Mutual monitoring of FR wheel speed sensor CAUTION • If there is any problem in the CAN bus lines, an incor- rect DTC may be set. Prior to this diagnosis, diagnose − CAN Bus Line Diagnostic Flow • Whenever ECU is replaced, ensure that the CAN bus lines are normal. • When the hydraulic unit (integrated with ASC-ECU) is replaced, always carry out the calibration of the steer-
and . OPERATION • Each wheel speed detecting section is a kind of a pulse generator. It consists of the encoder (plate on which the • The pulse signals generated by the wheel speed detecting section are sent to ASC-ECU. ASC-ECU uses the fre- . DTC SET CONDITIONS ASC-ECU monitors the signals from each wheel speed sensor • Missing wheel speed sensor signal • Wheel speed sensor signal continuously indicates low value. . PROBABLE CAUSES Current trouble • Excessive gap between the wheel speed sensor and the wheel speed detection encoder |
