Mitsubishi Outlander GS45X. Manual - part 333

SPARE CONNECTOR (FOR HANDS-FREE INTERFACE SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-413

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

RADIO AND CD PLAYER

<VEHICLES WITHOUT MMCS>

SPARE CONNECTOR (FOR HANDS-FREE INTERFACE SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-414

SPARE CONNECTOR (FOR HANDS-FREE INTERFACE SYSTEM) (CONTINUED)

MULTIVISION DISPLAY

<VEHICLES WITH MMCS>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SPARE CONNECTOR
(FOR HANDS-FREE INTERFACE SYSTEM)

SPARE CONNECTOR (FOR HANDS-FREE INTERFACE SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-415

NOTES

SPARE CONNECTOR (FOR TRAILER LIGHTS)

TSB Revision

CIRCUIT DIAGRAMS

90-416

SPARE CONNECTOR (FOR TRAILER LIGHTS)

M1901029701054

FUSIBLE
LINK

34

POWER
DISTRIBUTION
SYSTEM

ETACS-
ECU

STOPLIGHT
SWITCH

STOPLIGHT
RELAY

STOPLIGHT

·GLOVE BOX LIGHT
·HEATED SEAT
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM

SPARE CONNECTOR (FOR SWITCH BOX)

TAILLIGHT
CONTROL CIRCUIT

·ANTI-LOCK
 BRAKING SYSTEM
 (ABS)
·ANTI-LOCK
 BRAKING SYSTEM
 (ABS)
 AND ACTIVE
 STABILITY CONTROL
 SYSTEM (ASC)
·CRUISE
 CONTROL SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·MFI SYSTEM
·SHIFT LOCK
 MECHANISM

SHIFT LOCK
MECHANISM
