THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR>
TSB Revision
CIRCUIT DIAGRAMS
90-409
<VEHICLES WITH KOS>
KEYLESS
OPERATION
KEY
RECEIVER ANTENNA MODULE
KEYLESS
ENTRY
RECEIVER
IMMOBILIZER
ANTENNA
TRANSPONDER
ID
CODE
KOS-
ECU
JOINT CONNECTOR
(CAN1)
CAN DRIVE
CIRCUIT
POWER
SUPPLY
: ·AIR CONDITIONING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER TONE ALARM
<VEHICLES WITH KOS>
·KEYLESS OPERATING SYSTEM (KOS)
·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT
AND LIGHTING MONITOR TONE ALARM
·TURN-SIGNAL LIGHT AND HAZARD
WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
AND ACTIVE STABILITY CONTROL
SYSTEM (ASC)
·BRAKE WARNING LIGHT,
FUEL WARNING LIGHT AND
OIL PRESSURE WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T
·INVECS-III CVT
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER
TONE ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE
ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT
AND LIGHTING MONITOR
TONE ALARM
·TIRE PRESSURE MONITORING
SYSTEM (TPMS)
·TURN-SIGNAL LIGHT
AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
:
NOTE
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
