THEFT-ALARM SYSTEM <VEHICLES WITHOUT THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-394

THEFT-ALARM SYSTEM <VEHICLES WITHOUT

THEFT-ALARM SENSOR>

M1901012401341

<VEHICLES WITH HALOGEN TYPE HEADLIGHT>

FUSIBLE
LINK

36

RELAY BOX

ENGINE
COMPARTMENT

HEADLIGHT
RELAY
(LOW)

HEADLIGHT
RELAY
(HIGH)

FIELD EFFECT
TRANSISTOR

NO
CONNECTION

3.0L ENGINE
<VEHICLES WITH ASC>

:

NOTE

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
ASSEMBLY
(RH)

<VEHICLES
WITHOUT DRL>

<VEHICLES
WITH DRL>

THEFT-ALARM SYSTEM <VEHICLES WITHOUT THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-395

<VEHICLES WITH DISCHARGE TYPE HEADLIGHT>

FUSIBLE
LINK

36

HEADLIGHT
CONTROL UNIT

HEADLIGHT
CONTROL UNIT

HEADLIGHT
ASSEMBLY
(RH)

SOLENOID

SOLENOID

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

RELAY BOX

ENGINE
COMPARTMENT

THEFT-ALARM SYSTEM <VEHICLES WITHOUT THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-396

THEFT-ALARM SYSTEM <VEHICLES WITHOUT THEFT-ALARM SENSOR> (CONTINUED)

FUSIBLE
LINK

36

ETACS-ECU

RELAY BOX

ENGINE
COMPARTMENT

THEFT-ALARM
HORN RELAY

THEFT-ALARM
HORN

HORN
(LOW)

HORN
(HIGH)

HORN
RELAY
