ANTI-LOCK BRAKING SYSTEM (ABS)

TSB Revision

CIRCUIT DIAGRAMS

90-313

ETACS-
ECU

STOPLIGHT
SWITCH

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)
·STOPLIGHT

STOPLIGHT
RELAY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

ANTI-LOCK BRAKING SYSTEM (ABS)

TSB Revision

CIRCUIT DIAGRAMS

90-314

ANTI-LOCK BRAKING SYSTEM (ABS) (CONTINUED)

ENGINE CONTROL
MODULE

INPUT SIGNAL

ACCELERATOR
PEDAL POSITION
SENSOR

SOLENOID
VALVE POWER
SUPPLY

SOLENOID VALVE

HYDRAULIC UNIT

JOINT
CONNECTOR
(CAN3)

JOINT CONNECTOR
(CAN2)

ANTI-LOCK BRAKING SYSTEM (ABS)

TSB Revision

CIRCUIT DIAGRAMS

90-315

MOTOR
POWER SUPPLY

ABS-ECU

MOTOR

(LH)

(LH)

(RH)

(RH)

FRONT WHEEL SPEED SENSOR

REAR WHEEL SPEED SENSOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

ANTI-LOCK BRAKING SYSTEM (ABS)

TSB Revision

CIRCUIT DIAGRAMS

90-316

ANTI-LOCK BRAKING SYSTEM (ABS) (CONTINUED)

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

FRONT SIDE

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ETACS-ECU

(FUSE    )

5

JOINT
CONNECTOR
(CAN2)
