REAR SEAT ENTERTAINMENT SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-290

REAR SEAT ENTERTAINMENT SYSTEM

M1901029400492

ETACS-
ECU

REAR DISPLAY UNIT

RELAY BOX

ENGINE
COMPARTMENT

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR HANDS-FREE
 INTERFACE SYSTEM)
·SPARE CONNECTOR
 (FOR NAVIGATION SYSTEM)
·SPARE CONNECTOR
 (FOR SATELLITE RADIO)

FUSIBLE
LINK

36

COMBINATION
METER

CPU

INTERFACE
CIRCUIT

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·AUDIO SYSTEM
·CRUISE CONTROL
 SYSTEM
·ELECTRONIC
 CONTROLLED AWD
·HANDS-FREE
 INTERFACE SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·S-AWC
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT

THEFT-ALARM
SYSTEM

·AIR CONDITIONING
 SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·DAYTIME RUNNING
 LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE
 ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

REAR SEAT ENTERTAINMENT SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-291

ACC
RELAY 2

ETACS-
ECU

IGNITION
SWITCH (ACC)

WIRELESS HEADPHONE

REMOTE
CONTROLLER

·AUDIO SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REMOTE CONTROLLED
 MIRROR

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

37

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

REAR SEAT ENTERTAINMENT SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-292

REAR SEAT ENTERTAINMENT SYSTEM (CONTINUED)

RADIO AND CD PLAYER

INPUT SIGNAL

STEERING WHEEL
AUDIO REMOTE
CONTROL SWITCH

OUTPUT SIGNAL

·FRONT DOOR SPEAKER
·REAR DOOR SPEAKER
·TWEETER

REAR DISPLAY UNIT

<VEHICLES WITHOUT MMCS AND AUDIO AMPLIFIER>
