Mitsubishi Outlander GS45X. Manual - part 281

AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-205

ETACS-ECU

INPUT SIGNAL

IMPACT SENSOR

CPU

CAN TRANSCEIVER
CIRCUIT

COMBINATION
METER

INTERFACE
CIRCUIT

CAN
DRIVE CIRCUIT

SRS-ECU

A/C-ECU

JOINT
CONNECTOR
(CAN1)

INPUT SIGNAL

·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING
 CONTROL SENSOR
 <VEHICLES WITH
 AUTOMATIC LIGHT>

AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-206

AIR CONDITIONING SYSTEM (CONTINUED)

28

FUSIBLE
LINK

29

FUSIBLE
LINK

CONDENSER
FAN RELAY

FAN
CONTROL
RELAY

RADIATOR
FAN RELAY

CONDENSER
FAN
MOTOR

ETACS-
ECU

RADIATOR
FAN
MOTOR

<2.4L ENGINE>

NOTE

: 2.4L ENGINE
: 3.0L ENGINE

AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-207

ETACS-
ECU

28

FUSIBLE
LINK

29

FUSIBLE
LINK

CONDENSER
FAN
RELAY

FAN
CONTROL
RELAY

RADIATOR
FAN
RELAY

CONDENSER
FAN
MOTOR

RADIATOR
FAN
MOTOR

<3.0L ENGINE>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

WINDSHIELD WIPER AND WASHER

TSB Revision

CIRCUIT DIAGRAMS

90-208

WINDSHIELD WIPER AND WASHER

M1901006105569

FUSIBLE
LINK

36

34

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

IG1
RELAY

LIN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

COLUMN-ECU

COLUMN
SWITCH

(HI)

(LO)

(INT)

(AUTO)

WINDSHIELD
WIPER SWITCH

(MIST)

ETACS-ECU

POWER
DISTRIBUTION
SYSTEM

RELAY BOX

ENGINE
COMPARTMENT

WINDSHIELD
WASHER
SWITCH

UPPER
SIDE

UPPER
SIDE

(      )

·AIR CONDITIONING SYSTEM
·AUDIO SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT
 AND OIL PRESSURE
 WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·METER AND GAUGE
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING
 LIGHT
·UNIVERSAL SERIAL
 BUS (USB) BOX

NOTE

VEHICLES WITHOUT AUTOMATIC LIGHT
VEHICLES WITH AUTOMATIC LIGHT
WINDSHIELD INTERMITTENT WIPER
INTERVAL ADJUSTING KNOB
<VEHICLES WITHOUT AUTOMATIC LIGHT>
WINDSHIELD RAIN SENSITIVE WIPER
FUNCTION ADJUSTING KNOB
<VEHICLES WITH AUTOMATIC LIGHT>

:

:

:
