HEADLIGHT <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-117

NOTES

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-118

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE

LIGHT AND LIGHTING MONITOR TONE ALARM

M1901001703775

REAR
COMBINATION
LIGHT

FUSIBLE
LINK

34

ETACS-
ECU

TAILLIGHT
CONTROL CIRCUIT

REAR
COMBINATION
LIGHT (RH)

LICENSE
PLATE
LIGHT (RH)

LICENSE
PLATE
LIGHT (LH)

POWER
DISTRIBUTION
SYSTEM

HEATED SEAT

GLOVE BOX LIGHT

SPARE CONNECTOR
(FOR TRAILER LIGHTS)

TAILLIGHT:
LH

TAILLIGHT:
RH

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-119

REAR SIDE
MARKER
LIGHT (RH)

REAR SIDE
MARKER
LIGHT (LH)

HEADLIGHT
ASSEMBLY

HEADLIGHT
ASSEMBLY

POSITION
LIGHT : LH

POSITION
LIGHT : LH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

TSB Revision

CIRCUIT DIAGRAMS

90-120

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING
MONITOR TONE ALARM (CONTINUED)

::

:

:

NOTE

COLUMN SWITCH

LIGHTING SWITCH

COLUMN-ECU

CAN
TRANSCEIVER
CIRCUIT

LED DRIVE
CIRCUIT

CPU

TONE ALARM

RHEOSTAT

COMBINATION METER

LIN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

FUSIBLE
LINK

36

IG1
RELAY

FRONT SIDE

RELAY BOX

ENGINE
COMPARTMENT

ETACS-
ECU

·AIR CONDITIONING SYSTEM
·IGNITION KEY REMINDER TONE
 ALARM <VEHICLES WITH KOS>
·KEYLESS OPERATING SYSTEM
 (KOS)
·THEFT-ALARM SYSTEM
 <VEHICLES WITH
 THEFT-ALARM SENSOR>

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND
 OIL PRESSURE WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·HANDS-FREE INTERFACE SYSTEM
·HEATED DOOR MIRROR

JOINT CONNECTOR
(CAN1)

(HEAD)

(TAIL)

(AUTO)

VEHICLES WITH AUTOMATIC
LIGHT
