HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-109

KEYLESS
ENTRY
RECEIVER

<VEHICLES WITH KOS>

ETACS-ECU

JOINT CONNECTOR
(CAN1)

RECEIVER ANTENNA
MODULE

KEYLESS
OPERATION
KEY

POWER
SUPPLY

KOS-ECU

(FUSE     )

8

(FUSE     )

12

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HEADLIGHT <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-110

HEADLIGHT <DISCHARGE TYPE>

M1901001507160

FUSIBLE
LINK

36

HEADLIGHT
CONTROL UNIT

HEADLIGHT
CONTROL UNIT

HEADLIGHT
ASSEMBLY
(RH)

SOLENOID

SOLENOID

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

RELAY BOX

ENGINE
COMPARTMENT

HEADLIGHT <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-111

COLUMN
SWITCH

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS)
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT
 AND OIL PRESSURE
 WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING
 TONE ALARM
·ELECTRONIC CONTROLLED AWD
·HANDS-FREE INTERFACE
 SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER
 TONE ALARM
·REAR WINDOW DEFOGGER
·S-AWC
·SEAT BELT WARNING
 TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL
 RESTRAINT SYSTEM (SRS)
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)

ETACS-ECU

(FUSE     )

8

ETACS-ECU

(FUSE     )

12

ETACS-ECU

LIN DRIVE
CIRCUIT

(AUTO)

COLUMN-ECU

VEHICLES WITH AUTOMATIC LIGHT

:

NOTE

LIGHTING
SWITCH

DIMMER
SWITCH

PASSING
SWITCH

POWER WINDOWS

THEFT-ALARM SYSTEM
<VEHICLES WITH
THEFT-ALARM SENSOR>

(HEAD)

(TAIL)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HEADLIGHT <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-112

HEADLIGHT <DISCHARGE TYPE> (CONTINUED)

LIN DRIVE
CIRCUIT

IGNITION
CONTROL
CIRCUIT

HEADLIGHT
BACKUP
CIRCUIT

IG1
RELAY

INTERFACE
CIRCUIT

IGNITION
SWITCH (IG1)

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

36

FUSIBLE
LINK

34

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

RELAY BOX

ENGINE
COMPARTMENT

·AIR CONDITIONING
 SYSTEM
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>
·KEYLESS OPERATING
 SYSTEM (KOS)
·THEFT-ALARM SYSTEM
 <VEHICLES WITH THEFT-
 ALARM SENSOR>
