IGNITION SYSTEM <3.0L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-41

NO.1
IGNITION
COIL

NO.3
IGNITION
COIL

NO.5
IGNITION
COIL

SPARK
PLUG

SPARK
PLUG

SPARK
PLUG

ENGINE
CONTROL
MODULE

RELAY BOX

(FUSE     )

21

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CHARGING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-42

CHARGING SYSTEM

M1901000706221

ETACS-
ECU

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

COMBINATION METER

LED DRIVE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

CPU

RHEOSTAT

LCD

(GENERATOR MALFUNCTION LIGHT)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

POWER
DISTRIBUTION
SYSTEM

GENERATOR
MALFUNCTION
LIGHT

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS)
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·CENTRAL DOOR LOCKING
 SYSTEM
·DAYTIME RUNNING LIGHT
 (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>

·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM
 (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

JOINT
CONNECTOR
(CAN1)

CHARGING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-43

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

FRONT SIDE

(FUSE     )

5

ETACS-ECU

ENGINE CONTROL MODULE

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CHARGING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-44

CHARGING SYSTEM (CONTINUED)

ENGINE
CONTROL
MODULE

FUSIBLE
LINK

33

FUSIBLE
LINK

36

GENERATOR

IC VOLTAGE REGULATOR

STATOR
COIL

STATOR
COIL

FIELD
COIL

INPUT SIGNAL

·CRANKSHAFT POSITION
 SENSOR
·ENGINE COOLANT
 TEMPERATURE SENSOR
·IGNITION SWITCH (ST)

<2.4L ENGINE>

RELAY BOX

ENGINE
COMPARTMENT
