DIAGNOSIS

TSB Revision

CVT

23A-101

LOGIC FLOW CHARTS (Monitor Sequence)

.

DTC SET CONDITIONS

Judgment Criteria

• Lockup/select switching solenoid valve activation

command (ON voltage): 1.42 volts or less (0.2
second)

• Lockup/select switching solenoid valve activation

command (OFF voltage): more than 1.42 volts
(0.2 second)

.

OBD-II DRIVE CYCLE PATTERN

Ignition switch : ON (start the engine and keep it for
10 seconds or more)

.

PROBABLE CAUSES

• Malfunction of valve body assembly (Faulty

lockup/select switching solenoid valve)

• Damaged wiring harness and connectors

• Malfunction of TCM

.

PROBABLE CAUSES

• Malfunction of valve body assembly (Faulty

lockup/select switching solenoid valve)

• Damaged wiring harness and connectors

• Malfunction of TCM

AC802632

START

Yes

No

             Torque converter clutch or
select switch solenoid activation command
          on at circuit voltage     1.42 V

             Torque converter clutch or
select switch solenoid activation command
          off at circuit voltage > 1.42 V

No

No

Good

Malfunction

END

Yes

Continuous failure for 0.2 sec

Yes

DIAGNOSIS

TSB Revision

CVT

23A-102

DIAGNOSTIC PROCEDURE

STEP 1. M.U.T.-III data list
Item 36: LU/SEL changeover SOL. output
Item 37: LU/SEL changeover SOL. monitor

OK: Check that the output and monitor do not differ
greatly.

Q: Is the check result normal?

YES : Intermittent malfunction
NO :  Go to Step 2.

STEP 2. Check the following connector:

• B-125 CVT assembly connector

• C-38 TCM connector

• A-12 Intermediate connector

Check the terminals for a contact status problem and internal
short circuit.
Q: Is the check result normal?

YES : Go to Step 3.
NO :  Repair the defective connector.

STEP 3. Check for open circuit and short to ground in the
wiring harness between the TCM connector and the CVT
assembly connector.
Between C-38 TCM connector (terminal No.14) and B-125 CVT
assembly connector (terminal No.4)
Q: Is the check result normal?

YES : Go to Step 4.
NO :  Repair the wiring harness.

STEP 4. Lockup/select switching solenoid valve single unit
check
Refer to

P.23A-146

.

Q: Is the check result normal?

YES : Go to Step 5.
NO :  Replace the valve body assembly.

STEP 5. Symptom recheck after erasing diagnostic trouble
code
Q: Is the check result normal?

YES : Intermittent malfunction
NO :  Replace TCM.

DIAGNOSIS

TSB Revision

CVT

23A-103

DTC P1745: Monitoring of Percentage Change in Pulley Ratio

.

DIAGNOSTIC FUNCTION

TCM conducts fault detection by monitoring the inter-
nal calculated value.

.

JUDGEMENT CRITERIA

Percentage change in pulley ratio is larger than the
standard value.

.

PROBABLE CAUSES

• Malfunction of TCM

DIAGNOSTIC PROCEDURE

STEP 1. Symptom recheck after erasing diagnosis code
Q: Is the check result normal?

YES : Intermittent malfunction
NO :  Replace TCM.

DTC P1773: Malfunction of ABS

.

DIAGNOSTIC FUNCTION

TCM detects the ABS abnormality.

.

DESCRIPTIONS OF MONITOR METHODS

• When the ABS error signal reception continues

for 0.5 seconds.

.

MONITOR EXECUTION

• When 1.05 seconds have elapsed after TCM

started (not during M.U.T.-III communication)

.

MONITOR EXECUTION CONDITIONS
(OTHER MONITOR AND SENSOR)

Other Monitor (There is no temporary DTC stored

in memory for the item monitored below)

• Not applicable

Sensor (The sensor below is determined to be

normal)

• Not applicable

.

DIAGNOSIS

TSB Revision

CVT

23A-104

LOGIC FLOW CHARTS (Monitor Sequence)

.

DTC SET CONDITIONS

Check Conditions

• Time after TCM start: more than 1.05 seconds.

Judgment Criteria

• ABS status: malfunction

.

OBD-II DRIVE CYCLE PATTERN

Ignition switch : ON (start the engine and keep it for
10 seconds or more, not during M.U.T.-III communi-
cation)

.

PROBABLE CAUSES

• Malfunction of the ABS system

• Malfunction of TCM

DIAGNOSTIC PROCEDURE

STEP 1. ABS system DTC check
Q: Is the ABS system DTC set?

YES : Carry out the troubleshooting for ABS.
NO :  Go to Step 2.

AC802633

START

Yes

No

Yes

No

Yes

No

Good

Malfunction

END

Continuous failure for 0.5 sec

ABS status is "Malfunction"

All secondary parameters
are in the enable condition.
