RECOMMENDED LUBRICANTS AND LUBRICANT CAPACITIES TABLE

TSB Revision

GENERAL

00-63

RECOMMENDED LUBRICANTS AND

LUBRICANT CAPACITIES TABLE

M1001001300872

RECOMMENDED LUBRICANTS

Lubricant

Specifications

Remarks

Engine oil

Engine oils displaying ILSAC certification
symbol ("Starburst" symbol) or conforming
to the API classification SM.

For further details, refer to
"LUBRICANTS
SELECTION" section.

Engine coolant

Dia queen super long life coolant premium
or equivalent*

*similar high quality ethylene
glycol based non-silicate,
non-amine, non-nitrate and
non-borate coolant with long
life hybrid organic acid
technology.

Clutch fluid

Conforming to Brake fluid DOT 3 or DOT 4 -

Transaxle oil

DIA QUEEN NEW MULTI GEAR OIL API
classification GL-3, SAE 75W-80

-

Transmission (CVT) fluid

DIA QUEEN CVTF-J1

-

Transfer oil

Hypoid gear oil API classification GL-5,
SAE 80

-

Rear differential gear oil

Hypoid gear oil API classification GL-5,
SAE 80

-

Driveshaft (inside of knuckle
bore) grease

Dowcorning/Molykote BR2 Plus

-

Driveshaft (PTJ boot, EBJ boot)
grease

Repair kit grease

-

Brakes fluid

Conforming to Brake fluid DOT 3 or DOT 4 -

Door hinges, back door hinges
lubricant

Engine oil

-

Wiper motor link rod lgrease

Multipurpose grease SAE J310, NLGI
No.1(mineral oil + Li)

-

Air conditioning compressor
refrigerant unit oil

SUN PAG 56

-

RECOMMENDED LUBRICANTS AND LUBRICANT CAPACITIES TABLE

TSB Revision

GENERAL

00-64

LUBRICANT CAPACITY TABLE

Description

Specification

Engine oil dm

3

 (qt)

Oil pan (excluding oil filter)

4.0 (4.23)

Oil filter

0.3 (0.32)

Engine coolant dm

3

 (qt)

Includes reserve tank

7.5 (7.9)

Reserve tank

0.65 (0.69)

Fuel tank dm

3

 (gal)

FWD

63 (16.6)

AWD

60 (15.8)

Clutch fluid

As required

Transaxle oil dm

3

 (qt)

2.5 (2.6)

Transmission (CVT) fluid dm

3

 (qt)

7.1 (7.5)

Transfer oil dm

3

 (qt)

0.49 (0.52)

Rear differential gear oil dm

3

 (qt)

0.5 (0.53)

Driveshaft (inside of knuckle bore) lgrease g (oz)

As required



[1.0

− 1.5  (0.04 − 0.05)]

Driveshaft (PTJ boot, EBJ boot)
grease g (oz)

PTJ boot grease

FWD-M/T

LH

210

± 10 (7.4 ± 0.3)

RH

185

± 10 (6.5 ± 0.3)

FWD-CVT

LH

210

± 10 (7.4 ± 0.3)

RH

210

± 10 (7.4 ± 0.3)

AWD-CVT

LH

200

± 10 (7.1 ± 0.3)

RH

210

± 10 (7.4 ± 0.3)

EBJ boot grease

120

± 10 (4.2 ± 0.3)

Brakes fluid dm

3

 (qt)

As required

Wiper motor link rodg rease g (oz)

As required

Air conditioning compressor
refrigerant unit oil dm

3

 (qt)

Compressor refrigerant unit

70

− 90 (2.4 − 3.0)

Each connection of refrigerant line

As required

RECOMMENDED LUBRICANTS AND LUBRICANT CAPACITIES TABLE

TSB Revision

GENERAL

00-65

LUBRICANT SELECTION

.

ENGINE OIL

CAUTION

Never use nondetergent or straight mineral oil.
Use only engine oils displaying the ILSAC certification symbol
("Starburst" symbol) on the container.

If these oils are not available, an API classification SM can be
used.

.

OIL VISCOSITY

The SAE grade number indicates the viscosity of the oil. A
proper SAE grade number should be selected according to
ambient temperature.

AC609011

ILSAC certification symbol
("Starburst" symbol)

AC

A

P

I

SE

RVICE

  S

M



SAE

0W-20

ACA01781

API service symbol

AD

-20

0

0

20

20

40

40

60

80

100

120

30

10

50

-10

-20

-30

F

C

ACA02197

SAE 0W-20

SCHEDULED MAINTENANCE TABLE

TSB Revision

GENERAL

00-66

SCHEDULED MAINTENANCE TABLE

M1001001401106

.

SCHEDULED MAINTENANCE SERVICE FOR EMISSION CONTROL AND PROPER
VEHICLE PERFORMANCE

Inspection and service should be performed any time
if a malfunction is observed or suspected.

NOTE: *: This maintenance is recommended but is not required to maintain the emissions warranty.

.

No. Emission control

system
maintenance

Service
intervals

Mileage in
thousands

15

30

45

60

75

90

105 120

Kilometers in
thousands

24

48

72

96

120 144 168 192

Months

12

24

36

48

60

72

84

96

1

Fuel system (tank,
pipe line and
connection, and fuel
tank filler tube cap)

Check for leaks

X

X

2

Fuel hoses

Check condition

X*

X

X

X

3

Air cleaner element

Replace

X

X

X

X

4

Evaporative emission
control system
(except evaporative
emission canister)

Check for leaks and clogging

X

X

5

Spark plugs

Iridium-tipped
type

Replace

Every 105,000 miles (168,000 km) or every 84
months

6

Intake and exhaust
valve clearance

Inspect and adjust

X

X

7

Drive belts (for the
generator and power
steering oil pump)

Check condition

X

X

X

X

8

Exhaust system
(connection portion of
muffler, muffler pipes
and converter heat
shields)

Check and service

X*

X

X

X
