SUNROOF

TSB Revision

BODY

42A-219

INSTALLATION SERVICE POINT

.

>>A<< FRONT DRAIN PIPE/REAR DRAIN PIPE
INSTALLATION

Install the grommet, and adjust the drain pipe projection as
shown.

INSPECTION

M1426001300231

SUNROOF SWITCH CONTINUITY CHECK

AC703557AB

60 ± 5
(2.35 ± 0.15)

60 ± 5
(2.35 ± 0.15)

<Front drain pipe>

<Rear drain pipe>

Grommet

Grommet

Unit: mm (inch)

Switch
position

Terminal
number

Normal value

Tilt-up

3

− 4

Continuity exists
(2

Ω or less)

OFF

3

− 4, 4 − 5, 4 −

6

Open circuit

Open

4

− 5

Continuity exists
(2

Ω or less)

Close/tilt-down 4

− 6

Continuity exists
(2

Ω or less)

AC703554AB

Sunroof switch

SUNROOF

TSB Revision

BODY

42A-220

DISASSEMBLY AND ASSEMBLY

M1426001400528

REMOVAL SERVICE POINTS

.

<<A>> SUNROOF SUNSHADE REMOVAL

CAUTION

Before removing the sunroof sunshade, clean the shaded
area of the sunroof housing shown in the illustration. Oth-
erwise, the sunroof sunshade may get dirty when it is
removed.

.

<<B>> SUNROOF DRIP PLATE AND SUNROOF
LID SLIDE GUIDE REMOVAL

Slide the slide part of the sunroof lid slide guide to the rear of
the sunroof housing, and then pull out the sunroof drip plate
and sunroof lid slide guide.

AC708942

1

2

3

4

5

6

7

8

9

10

AB

N

Disassembly steps

1.

Sunroof drip rail

2.

Sunroof sunshade stopper

3.

Sunroof sunshade knob

<<

A

>>

4.

Sunroof sunshade

<<

B

>>

>>

B

<<

5.

Sunroof drip plate and sunroof lid
slide guide

6.

Sunroof drip plate

7.

Sunroof lid slide guide

8.

Sunroof deflector

>>

A

<<

9.

Sunroof pad

10. Sunroof housing

Disassembly steps (Continued)

AC708959

AB

Sunroof housing

AC708960

AB

: Front of sunroof housing

Slide part

Sunroof lid slide guide

SUNROOF

TSB Revision

BODY

42A-221

INSTALLATION SERVICE POINTS

.

>>A<< SUNROOF PAD INSTALLATION

Align the sunroof pad with the mark on the sunroof housing,
and then install it.

.

>>B<< SUNROOF DRIP PLATE AND SUNROOF
LID SLIDE GUIDE INSTALLATION

1. Install the sunroof drip plate and sunroof lid slide guide to

the sunroof housing.

2. Push the sunroof drip plate and sunroof lid slide guide

toward the front of sunroof housing until they stop.

CAUTION

If the slide part of the sunroof lid slide guide is positioned
incorrectly, the sunroof may not work normally.
3. Push the slide part of the sunroof lid slide guide forward.

Align the pin center of the slide part with the location shown
in the illustration.

AC708962

AB

: Front of sunroof housing

Mark

Sunroof pad

Sunroof housing

AC708961

AB

: Front of sunroof housing

Slide part

Sunroof lid slide guide

Pin

LOOSE PANEL

TSB Revision

BODY

42A-222

LOOSE PANEL

REMOVAL AND INSTALLATION

M1421003101071

INSTALLATION SERVICE POINT

.

>>A<< HEADLIGHT SUPPORT UPPER PANEL
INSTALLATION

Install the mounting bolts of headlight support upper panel in
the order shown in the illustration.

AC900200AB

5

4

3

1

2

9.0 ± 1.0 N·m

<Headlight support upper panel>

9.0 ± 2.0 N·m

9.0 ± 2.0 N·m

9.0 ± 2.0 N·m

80 ± 17 in-lb

80 ± 17 in-lb

80 ± 17 in-lb

80 ± 8 in-lb

Headlight support upper panel
removal steps

• Headlight support panel cover (Refer

to GROUP 51

−Radiator grille

P.51-9

.)

• Front bumper (Refer to GROUP

51

−Front Bumper

P.51-4

.)

• Headlight (Refer to GROUP

54A

−Headlight

P.54A-212

.)

1. Headlight support upper panel cover
2. Hood lock release cable

3. Hood latch
4. Air cleaner intake duct
• Front impact sensor (Refer to

GROUP 52B

− Front impact sensor

P.52B-433

.)

• Front harness

>>

A

<< 5. Headlight support upper panel

Headlight support upper panel
removal steps (Continued)

AC900234AB

Headlight support
upper panel

1

5

2

3

6

4

7

8
