HARNESS CONNECTOR INSPECTION TSB Revision GENERAL <ELECTRICAL> 00E-5 3. Press the contact point to the male terminal down by holding a screwdriver [1.4 mm (0.06 inch) width] as shown in the . INJECTOR CONNECTOR 1. Remove the waterproof cap. 2. Insert the tip of a screwdriver [1.4 mm (0.06 inch) width] into the connector as shown in the figure, press in the terminal CAUTION Make sure the lance is pressed in before the terminal is a screwdriver [1.4 mm (0.06 inch) width] as shown in the ACX00912 ACX00913AB WATERPROOF AC310304AB TERMINAL LANCE AC310313 |
