RADIO AND CD PLAYER

TSB Revision

CHASSIS ELECTRICAL

54A-325

COLUMN SWITCH (SWITCH BODY PART)
CONTINUITY CHECK

M1543100800069

1. Remove the lighting switch and the wiper/washer switch.
2. Check that the continuity is present for the same terminal

numbers (No. 2-11) of the column switch body connectors
that remain on the steering column.

RADIO AND CD PLAYER

GENERAL INFORMATION

M1544000101382

The unique panel audio (radio and CD player, CD changer
built-in type radio and CD player) gives a sense of unity with
the instrument panel. Also, a new function automatically cor-
rects the sound quality and volume during driving.

Windshield
wiper switch

Hi

6

− 8

Continuity exists
(2

Ω or less)

Lo

6

− 9

Continuity exists
(2

Ω or less)

Auto 6

− 10

Continuity exists
(2

Ω or less)

Mist

6

− 11

Continuity exists
(2

Ω or less)

Switch position

Tester
connection

Specified
condition

Column switch
body

Tester
connection

Specified
condition

• Lighting switch

side connector

• Wiper/washer

switch side
connector

2

− 2

3

− 3

4

− 4

5

− 5

6

− 6

7

− 7

8

− 8

9

− 9

10

− 10

11

− 11

Continuity exists
(2

Ω or less)

AC502901AG

1

6

8

11

10

9

7

5

4

3

2

1

6

8

11

10

9

7

5

4

3

2

Lighting
switch side

Wiper/washer
switch side

AC606299AH

Unique panel audio

RADIO AND CD PLAYER

TSB Revision

CHASSIS ELECTRICAL

54A-326

With the exception of some models, the vehicles with audio
amplifier have the external connection jack (audio
adapter).Therefore, portable music player and so on can be
connected.

NOTE:

.

•

*1

: CD-R/CD-RW may not be played.

•

*2

: Some may not be played.

AC809504

AB

Audio adopter

Rear floor console

Item

radio and CD player

CD changer built-in type
radio and CD player

Electronic tuning radio

Equipped

Equipped

SIRIUS satellite radio

−

Equipped (Only the vehicles
with the satellite radio tuner)

USB

Equipped (Only the vehicles
with the USB box or hands
free module)

Equipped (Only the vehicles
with the USB box or hands
free module)

Hands free interface system

Equipped (Only the vehicles
with the hands free module)

Equipped (Only the vehicles
with the hands free module)

CD player

*1

 (compatible with MP3

*2

)

Equipped

Equipped

6-disk CD autochanger

*1

 (compatible with

MP3

*2

)

−

Equipped

Audio integrated 4-ch power amplifier and
digital signal processor (DSP)

General 140 W

General 140 W

Audio amplifier-integrated 8-ch power amplifier
and digital signal processor (DSP) <Rockford
Fosgate

® premium sound system>

−

General 710 W (maximum)

RADIO AND CD PLAYER

TSB Revision

CHASSIS ELECTRICAL

54A-327

SPECIAL TOOLS

M1542000602555

Tool

Tool number and
name

Supersession

Application

MB990784
Ornament remover

General service tool

Removal of center outlet, center
panel or cover.

MB991958

a. MB991824
b. MB991827
c. MB991910
d. MB991911
e. MB991914
f. MB991825
g. MB991826

M.U.T.-III sub
assembly

a. Vehicle

communication
interface (V.C.I.)

b. M.U.T.-III USB

cable

c. M.U.T.-III main

harness A
(Vehicles with
CAN
communication
system)

d. M.U.T.-III main

harness B
(Vehicles without
CAN
communication
system)

e. M.U.T.-III main

harness C (for
Chrysler models
only)

f. M.U.T.-III

measurement
adapter

g. M.U.T.-III trigger

harness

MB991824-KIT
NOTE: G: MB991826
M.U.T.-III Trigger
Harness is not
necessary when
pushing V.C.I. ENTER
key.

CAUTION

M.U.T.-III main harness A
(MB991910) should be used.
M.U.T.-III main harness B and C
should not be used for this
vehicle.
Diagnostic trouble code or service
data check.

MB990784

MB991910

MB991826

MB991958

MB991911

MB991914

MB991824

MB991827

MB991825

DO NOT USE

a

b

c

d

e

f

g

DO NOT USE

RADIO AND CD PLAYER

TSB Revision

CHASSIS ELECTRICAL

54A-328

DIAGNOSIS

INTRODUCTION TO AUDIO SYSTEM DIAGNOSIS

M1544004700725

RADIO AND CD PLAYER ERROR CODES

If the radio and CD player detects any malfunction in
itself or the inserted CD, the error codes below will
be shown on the display.

MB991223

a. MB991219
b. MB991220
c. MB991221
d. MB991222

Harness set

a. Test harness
b. LED harness
c. LED harness

adaptor

d. Probe

General service tools Continuity check and voltage

measurement at harness wire or
connector for loose, corroded or
damaged terminals, or terminals
pushed back in the connector.

a. Connector pin contact

pressure inspection

b. Power circuit inspection
c. Power circuit inspection
d. Commercial tester connection

MB992006
Extra fine probe

−

Continuity check and voltage
measurement at harness wire or
connector for loose, corroded or
damaged terminals, or terminals
pushed back in the connector.

Tool

Tool number and
name

Supersession

Application

MB991223

a

d

c

b

DO NOT USE

BA

MB992006

Error code

Cause

Cause of trouble and its solution

ERROR

Power supply error

This error code will be shown if there is any problem in the
power supply system of the radio and CD player. Check the
connectors and wiring harness of the power supply system, and
check that the battery voltage is normal. Check that the same
error does not appear.

ERROR 01

Focus error

These error codes will be shown if there is any problem with the
CD or there is excessive vibration on the vehicle. If the error
codes are not displayed when the vehicle is stopped and
another CD is inserted, there is a problem with the CD. Check if
there is any of the following problems with the CD.

• Contamination, scratch, or deformation

• Formation of moisture or grease

Repair the CD and insert it again. Then, check that no error
appears.

ERROR 02

Abnormal disc

ERROR 03

Mechanical error

This error codes will be shown if there is any internal
mechanical or electrical problem in the radio and CD player.
Replace the radio and CD player check that no error codes are
shown.
