Mitsubishi Outlander GS45X. Manual - part 55





HEADLIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-217

LIGHTING CONTROL SENSOR REMOVAL AND INSTALLATION

M1540108500223

AC709252

Optical coupler

AB

1

2

3

Note
         : Claw positions

A

A

Section A - A

Section B - B

Section C - C

Section D - D

Optical coupler

3

D

C

B

D

C

1

1

1

Claw

Claw

Lighting control
sensor bracket

Lighting control
sensor bracket

Lighting control
sensor bracket

Lighting control
sensor bracket

Claw

Claw

Claw

B

Removal Steps

1.

Lighting control sensor cover

2.

Connector

<<

A

>>

>>

A

<<

3.

Lighting control sensor

Removal Steps (Continued)

HEADLIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-218

REMOVAL SERVICE POINT

.

<<A>> LIGHTING CONTROL SENSOR REMOVAL

While pushing the clamp to the windshield side, pry up the
clamp to disengage the right and left claws using the screw-
driver (

−), and then remove the lighting control sensor.

INSTALLATION SERVICE POINT

.

>>A<< LIGHTING CONTROL SENSOR INSTALLA-
TION

CAUTION

After executing the lighting control sensor (rain sensor)
adaptation, do not touch the lighting control sensor (or do
not move it from the fixed position).

• Mount the lighting control sensor onto the optical coupler,

and then connect the connector.

• When reusing the lighting control sensor or when the light-

ing control sensor is pushed to check the installation condi-
tion, install the connector and the lighting control sensor
cover and wipe the windshield thoroughly. When the wind-
shield is dry, execute the lighting control sensor (rain sen-
sor) adaptation. <Refer to GROUP 51

− Lighting Control

Sensor (Rain Sensor) Adaptation

P.51-85

>.

NOTE: Be careful not to touch the lighting control sensor
receiver. (The lighting control sensor receiver has limited resis-
tance to oil.)

AC700066

Screwdriver (-)

AG

Claw

Lighting
control
sensor

Clamp

Push

Push

HEADLIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-219

INSPECTION

HEADLIGHT RELAY CHECK

M1540104000196

HEADLIGHT RELAY (LOW) CHECK <VEHICLES
WITH DISCHARGE HEADLIGHT>

HEADLIGHT RELAY (HIGH) CHECK

Battery voltage

Terminal
number

Normal
conditions

Not energized

− 4

No
continuity

With current supply
[terminal 2 (+), terminal 1
(

−)]

Continuity
exists (2
ohms or
less)

AC702996

2

3

4

1

AC

Headlight relay (LOW)

Headlight relay
(LOW)

A-28X

Battery voltage

Terminal
number

Normal
conditions

Not energized

− 4

No
continuity

With current supply
[terminal 2 (+), terminal 1
(

−)]

Continuity
exists (2
ohms or
less)

AC702996

2

3

4

1

AB

Headlight relay (HIGH)

Headlight relay
(HIGH)

A-20X

HEADLIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-220

DAYTIME RUNNING LIGHT RELAY CHECK
<VEHICLES WITH DISCHARGE HEADLIGHT>

M1540113400017

HEADLIGHT LEVELING SWITCH CHECK

M1540101300325

LIGHTING CONTROL SENSOR (LIGHT SENSOR)
CHECK

M1540109000180

Using the scan tool MB991958, check the LIN data list as fol-
lows.
1. Under the direct sunlight, turn the ignition switch to the ON

position and the lighting switch to the AUTO position.

2. When the lighting control sensor receiver is covered by

hand, and if the item No. 7009 (RLS Low beam "ON"
request) and the item No. 7011 (RLS Taillight "ON" request)
turn from OFF to ON, it is judged normal.

NOTE:

.

Battery voltage

Terminal
number

Normal
conditions

Not energized

− 4

No
continuity

With current supply
[terminal 1 (+), terminal 2
(

−)]

Continuity
exists (2
ohms or
less)

AC803406

1

3

4

2

AB

Daytime running
light relay

A-23X

Daytime running light relay

Measured
terminals

Switch
position

Resistance value
Ω

− 6

0

750

1

1,110

2

1,470

3

1,830

4

2,190

− 6

0, 1, 2, 3, 4

2,810

AC700633AD
