ELECTRIC POWER STEERING SYSTEM

CIRCUIT DIAGRAMS

90-136

ELECTRIC POWER STEERING SYSTEM (CONTINUED)

ETACS-
ECU

FRONT SIDE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DIAGNOSIS
CONNECTOR

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

EPS-ECU

NOTE

INPUT SIGNAL

CRANK ANGLE
SENSOR

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

ABS-ECU

ETACS-ECU

(FUSE     )

11

(FUSE     )

15

ENGINE-ECU

COMBINATION
METER

: VEHICLES WITHOUT ASC
: VEHICLES WITH ASC

: VEHICLES WITHOUT COLOUR

LIQUID CRYSTAL DISPLAY

RHEOSTAT

LCD (EPS)

LED DRIVE
CIRCUIT

CPU

CAN TRANSCEIVER
CIRCUIT

HEATED SEAT

CIRCUIT DIAGRAMS

90-137

HEATED SEAT

M1901010702628

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

ETACS-ECU

EARTH J/C
(DASH)

HEATED SEAT SWITCH

LH

RH

RELAY BOX

HEATER
CONTROLLER
ASSEMBLY
(A/C-ECU)

HEATED
SEAT
RELAY

IG1
RELAY

PASSENGER
COMPARTMENT

RELAY BOX

ENGINE
COMPARTMENT

IGNITION SWITCH (IG1)
OR OSS-ECU (IG1)

NOTE

: VEHICLES WITHOUT KOS
: VEHICLES WITH KOS
: ·ABS-ECU

·ASC-ECU
·COLUMN SWITCH
·CORNER SENSOR/ BACK SENSOR-ECU
·CVT CONTROL RELAY
·EPS-ECU
·HAZARD INDICATOR ASSEMBLY
·HEATER CONTROLLER
 ASSEMBLY (A/C-ECU)
·KOS-ECU
·SELECTOR LEVER ASSEMBLY
·SONAR SWITCH
·STEERING WHEEL SENSOR
·SUNROOF MOTOR ASSEMBLY

FUSIBLE
LINK

2

FUSIBLE
LINK

4

INPUT SIGNAL

·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING CONTROL SENSOR
 <VEHICLES WITH AUTO LAMP
 AND RAIN SENSITIVE AUTO
 WIPER>

HEATED SEAT

CIRCUIT DIAGRAMS

90-138

HEATED SEAT (CONTINUED)

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

HEATED SEAT SWITCH

HEATED
SEAT (RH)

THERMOSTAT

SEAT
BACK
HEATER

THERMOSTAT

SEAT
CUSHION
HEATER

HEATED SEAT SWITCH

HEATED
SEAT (LH)

THERMOSTAT

SEAT
BACK
HEATER

THERMOSTAT

SEAT
CUSHION
HEATER

HEATED SEAT (CONTINUED)

CPU

RHEOSTAT

HIGH SIDE
DRIVE CIRCUIT

LOW SIDE
DRIVE CIRCUIT

HEATER
CONTROLLER
ASSEMBLY
(A/C-ECU)

HEATED SEAT
SWITCH

ETACS-ECU

(FUSE     )

19

(FUSE     )

15

COMBINATION METER

NOTE

: ·4WD SWITCH

·ASC OFF SWITCH
·DOWNLIGHT
·ELECTRIC TAILGATE SWITCH
·HAZARD INDICATOR ASSEMBLY
·HEADLAMP MANUAL LEVELLING SWITCH
·METER INFORMATION SWITCH
·SONAR SWITCH

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White
Y : Yellow     SB : Sky blue     BR : Brown     O : Orange     GR : Grey
R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

POWER SEAT

CIRCUIT DIAGRAMS

90-139

POWER SEAT

M1901010401583

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

POWER SEAT
ASSEMBLY

FRONT HEIGHT SWITCH

FRONT HEIGHT MOTOR

CIRCUIT
BREAKER

REAR HEIGHT SWITCH

REAR HEIGHT MOTOR

CIRCUIT
BREAKER

SLIDE SWITCH

SLIDE MOTOR

CIRCUIT
BREAKER

RECLINING SWITCH

RECLINING MOTOR

CIRCUIT
BREAKER

PASSENGER
COMPARTMENT

RELAY BOX

ETACS-ECU

FUSIBLE
LINK

2

ACC RELAY 3, FUSE,
FUSIBLE LINK, IG1 RELAY
AND TAIL LAMP
CONTROL CIRCUIT
