Mitsubishi Outlander (2013+). Manual - part 754

ACB04717AB

Rear wheel
speed sensor

Rear wheel
speed sensor
(LH) connector

Y

Rear wheel
speed sensor
(RH) connector

ACB04439AB

Rear corner
sensor

<Vehicles with reversing sensor
system>

Back sensor

Z

SOLENOID AND SOLENOID VALVE

COMPONENT LOCATIONS

70-11

SOLENOID AND SOLENOID VALVE

M1701000802363

Name

Symbol

Name

Symbol

CVT assembly (incorporating CVT
control solenoid valve)

D

Purge control solenoid valve

C

Electronic control coupling solenoid
<4WD>

G

Selector lever assembly (incorporating
shift lock solenoid)

F

Hydraulic unit (incorporating solenoid
valve)

A

Steering lock solenoid <Vehicles
without KOS>

E

Inlet oil feeder control valve

B

ACB04465

A

E

AE

B

C

D

F

ACB04714AD

G

ACB04418

A

AB

Hydraulic unit
(incorporating
solenoid valve)

AC506592AT

Inlet oil feeder
control valve

Intake manifold

B

ACB04432AB

Purge control
solenoid valve

Inlet manifold

C

AC506934

CVT assembly
(incorporating CVT
 control solenoid valve)

Front drive
shaft (LH)

CVT assembly
connector

AT

D

SOLENOID AND SOLENOID VALVE

COMPONENT LOCATIONS

70-12

AC905234AG

<Vehicles without KOS>

Steering
shaft

Steering lock
solenoid

E

ACB04713AB

Selector lever
assembly
(incorporating
shift lock solenoid)

F

AC505982AF

Electronic control
coupling solenoid

G

<4WD>

FUSIBLE LINK AND FUSE

COMPONENT LOCATIONS

70-13

FUSIBLE LINK AND FUSE

M1701000101714

Name

Symbol

Name

Symbol

Fuse Nos.3 to 23 and 25 (Passenger
compartment)

C

Fusible link Nos.SBF1 to SBF7 (Engine
compartment)

B

Fuse Nos.BF1 to BF3 and F1 to F22
(Engine compartment)

B

Fusible link Nos.1 to 5 (Connected
directly to battery positive terminal)

A

Fusible link Nos.1, 2 and 24
(Passenger compartment)

C

ACB04465AF

A

B

C

ACB04415

Fusible link
Nos.1 to 5

Battery

A

AB

ACB04409

Fusible link
Nos.SBF1 to SBF7

Relay box

B

AB

ACB04410

Fuse Nos.
BF1 to BF3
and F1 to F22

Relay box

B

AB

ACB04412

C

AB

Fusible link No.1 and 2

Fusible link No.24

ETACS-ECU

ACB04413

C

AB

Fuse Nos.3 to 25

ETACS-ECU

INSPECTION CONNECTOR AND SPARE CONNECTOR

COMPONENT LOCATIONS

70-14

INSPECTION CONNECTOR AND SPARE CONNECTOR

M1701000201250

Name

Symbol

Name

Symbol

Diagnosis connector

B

Spare connector (for trailer harness)

A

Spare connector (for switch box)

C
