SENSOR
COMPONENT LOCATIONS
70-7
NOTE: *:also equipped at the right side.
Ambient temperature sensor
L
Manifold absolute pressure sensor
H
Back sensor <Vehicles with reversing
sensor system>
Z
Oxygen sensor (front)
C
Crank angle sensor
I
Oxygen sensor (rear)
V
Detonation sensor
B
Primary pulley speed sensor
M
Electronic-controlled throttle valve
(incorporating throttle position sensor)
J
Rear corner sensor <Vehicles with
reversing sensor system>
Z
Engine coolant temperature sensor
E
Rear height sensor <Vehicles with
headlamp automatic levelling system>
X
Fin thermo sensor
Q
Rear wheel speed sensor
Y
Front height sensor <Vehicles with
headlamp automatic levelling system>
T
Secondary pulley speed sensor
K
Front impact sensor
G
Side impact sensor
W
Front wheel speed sensor
U
Steering wheel sensor <Vehicles with
ASC>
N
Inlet camshaft position sensor
D
Tailgate sensor <Vehicles with electric
tailgate>
S
ACB04465AD
A
D
E
F
G
C
B
H
I
J
K
L
M
N
O
P
Q
*
ACB04714AC
R
S
T
U
V
W
X
Y
Z
*
*
*
*
*
Name
Symbol
Name
Symbol
