Mitsubishi Outlander (2013+). Manual - part 513

ACB05819

ACB05820

ACC00269

Marking

AB

A

A

Section A – A

Marking

TAILGATE <VEHICLES WITHOUT ELECTRIC TAILGATE>

BODY

42A-72

The marking on the tailgate opening weatherstrip
should be positioned at the centre of the body.

>>B<< TAILGATE HINGE INSTALLATION

AC402763AB

Tailgate hinge

Apply the specified sealant to the tailgate hinge
mounting surface, and install the tailgate hinge.

Specified Adhesive: 3M ATD Part No.8531
Heavy drip check sealer, 3M ATD Part
No.8646 Automotive joint and seam sealer or
equivalent

TAILGATE HANDLE AND LATCH

REMOVAL AND INSTALLATION

M1424001701076

Post-installation operation
• Tailgate alignment (Refer to

P.42A-68

.)

ACC00333

22 ± 3 N·m

9.0 ± 1.0 N·m

2

1

3

AB

4

5.0 ± 1.0 N·m

Striker removal steps

•

Rear end trim (Refer to GROUP
52A

− Interior trims .)

>>

B

<<

1.

Striker
Tailgate lock release handle
removal steps

•

Tailgate trim (Refer to GROUP 52A
− Tailgate trims .)

•

Rear wiper motor assembly (Refer
to GROUP 51 -Rear Wiper and
Washer .)

2.

Tailgate lock release handle
Tailgate latch removal steps

•

Tailgate trim (Refer to GROUP 52A
− Tailgate trims .)

3.

Earth bolt

>>A<<

4.

Tailgate latch assembly

TAILGATE <VEHICLES WITHOUT ELECTRIC TAILGATE>

BODY

42A-73

INSTALLATION SERVICE POINTS

>>A<< TAILGATE LATCH ASSEMBLY
INSTALLATION

ACC00338AB

1

3

2

Install the tailgate latch assembly mounting bolts in
the numerical order.

>>B<< STRIKER INSTALLATION

AC402863AB

+1.5 mm

-1.5 mm

Striker centre

Striker

Latch centre

Latch

Install the striker so that the striker centre does not
deviate more than

±1.5 mm from the latch centre.

INSPECTION

M1424001800304

TAILGATE LOCK RELEASE HANDLE
(TAILGATE OPEN SWITCH) CHECK

ACC00262AB

Open switch

Switch
position

Terminal
number

Normal value

Push (open)

1

− 2

Continuity
exists (2

Ω or

less)

Release

1

− 2

No continuity

TAILGATE LOCK ACTUATOR CHECK

ACB05959AB

Set

Lever

Open

Lever
position

Battery
connection

Lever operation

At the
"SET"
position

• Connect

terminal 2 to
negative battery
terminal.

• Connect

terminal 3 to
positive battery
terminal.

Lever moves
from "SET" to
"OPEN" position.

TAILGATE <VEHICLES WITH ELECTRIC TAILGATE>

BODY

42A-74

TAILGATE LATCH SWITCH CHECK

AC905470

ACB05958

ACC00366AB

Unlatch
(ON)

Half-latch
(ON)

Full-latch
(OFF)

Claw position

Terminal
number

Normal value

Unlatch (ON)/
Half-latch (ON)

1

− 2

Continuity
exists (2

Ω or

less)

Full-latch (OFF) 1

− 2

No continuity

TAILGATE <VEHICLES WITH ELECTRIC TAILGATE>

SERVICE SPECIFICATIONS

M1424000300072

Item

Standard value

Electric tailgate operating current (power supply 14.5

± 0.5 V at 25°C)  A

11 or less

ADHESIVE

M1424000500322

Application

Brand name

Tailgate hinge

3M ATD Part No.8531 Heavy drip check sealer, 3M
ATD Part No.8646 Automotive joint and seam sealer
or equivalent

SPECIAL TOOLS

M1424000600664

Tool

Number

Name

Use

MB990925AF

A

MB990925

A: MB990939

Bearing and oil seal
installer set

A: Remover bar

Tailgate striker adjustment

ACB05421

MB992745

MB992746

MB992744

MB992747

MB992748

a

b

c

d

e

DO NOT USE

AB

TAILGATE <VEHICLES WITH ELECTRIC TAILGATE>

BODY

42A-75

a. MB992744
b. MB992745
c. MB992746
d. MB992747
e. MB992748

a. Vehicle

communication
interface-Lite
(V.C.I.-Lite)

b. V.C.I.-Lite main

harness A (for
vehicles with
CAN
communication)

c. V.C.I.-Lite main

harness B (for
vehicles without
CAN
communication)

d. V.C.I.-Lite USB

cable short

e. V.C.I.-Lite USB

cable long

ECU check (M.U.T.-III diagnosis
code display and service data
display)

Tool

Number

Name

Use
