DOOR

BODY

42A-48

1. Open a door that is supposed to be checked.

2. Remove a door trim assembly (Refer to GROUP

52A

− Door Trim ).

3. Use a screwdriver or the like to slide the door

latch claw from unlatch to full-latch position (Set
the door latch from door-open to door-closed
condition).

DOOR LOCK ACTUATOR

AC904658

ACB05670

ACC00088AB

Door inside lock cable

Door inside
handle cable

Door inside
handle
lock knob

Door inside handle knob

Lock

Unlock

Door latch assembly
connector

Claw

Claw

Claw

<Unlatch>

<Half-latch (door-ajar)>

<Full-latch>

ACTUATOR OPERATION CHECK <FRONT LH
AND REAR LH>

Claw
position

Door inside
handle lock
knob
position

Battery
connection

Door inside
handle lock
knob
operation

Full-latch Lock

• Connect

terminal
1 to
negative
battery
terminal.

• Connect

terminal
2 to
positive
battery
terminal.

Knob moves
from "Lock"
to "Unlock"
position.

Full-latch Unlock

• Connect

terminal
1 to
positive
battery
terminal.

• Connect

terminal
2 to
negative
battery
terminal.

Knob moves
from
"Unlock" to
"Lock"
position.

Claw
position

Door inside
handle lock
knob
position

Battery
connection

Door inside
handle lock
knob
operation

DOOR

BODY

42A-49

ACTUATOR OPERATION CHECK <FRONT RH
AND REAR RH>

Claw
position

Door inside
handle lock
knob
position

Battery
connection

Door inside
handle lock
knob
operation

Full-latch Lock

• Connect

terminal
4 to
negative
battery
terminal.

• Connect

terminal
3 to
positive
battery
terminal.

Knob
moves from
"Lock" to
"Unlock"
position.

Full-latch Unlock

• Connect

terminal
4 to
positive
battery
terminal.

• Connect

terminal
3 to
negative
battery
terminal.

Knob
moves from
"Unlock" to
"Lock"
position.

ACTUATOR SWITCH CHECK <FRONT LH>

Claw
position

Door inside
handle lock
knob
position

Tester
connection

Specified
condition

Full-latch

Lock

6

− 8

No
continuity

Full-latch

Unlock

6

− 8

Continuity
exists (2

Ω

or less)

ACTUATOR SWITCH CHECK <FRONT RH: VEHI-
CLES WITH KOS>

Claw
position

Door inside
handle lock
knob
position

Tester
connection

Specified
condition

Full-latch

Lock

7

− 9

No
continuity

Full-latch

Unlock

7

− 9

Continuity
exists (2

Ω

or less)

DOOR OUTSIDE HANDLE ASSEMBLY
PLAY CHECK

M1423001600749

AC507361

ACC00094

ACB04939

A

A

B

AB

Section A – A

1. Check that the door outside handle assembly play

(stroke until the door latch unlocks) meets the
standard value.

Standard value (B): 0.2

− 5.2 mm [Target

value: 2.7 mm]

2. Check the door outside handle assembly and

door latch assembly. Replace them if the play is
out of the standard value.

DOOR

BODY

42A-50

DOOR INSIDE HANDLE CHECK

M1423001500816

DOOR INSIDE HANDLE KNOB PLAY
CHECK

AC905463

ACC00096

ACB04940

A

A

B

AB

Section A – A

1. Check that the door inside handle knob play

(stroke until the door latch unlocks) meets the
standard value.

Standard value (B): 13.6

− 27.2 mm [Target

value: 20.4 mm]

2. Check the door inside handle knob and door latch

assembly. Replace them if the play is out of the
standard value.

DOOR INSIDE HANDLE LOCK KNOB
STROKE CHECK

1. Remove the door trim assembly (Refer to GROUP

52A

− Door Trim ).

AC905464

ACB04941

ACC00095

A

B

AB

A

Section A – A

2. Check that the stroke of the door inside handle

lock knob meets the standard value.

Standard value (B): 13.5

− 15.5 mm [Target

value: 14.5 mm]

3. Check the door inside handle lock knob and door

latch assembly. Replace them if the stroke is out
of the standard value.

CUSTOMISATION FUNCTION

M1429007801021

By operating the M.U.T.-III ETACS system, the fol-
lowing functions can be customised. The pro-
grammed information is held even when the battery
is disconnected.

Adjustment
item (M.U.T.-III
display)

Adjustment item

Adjusting content
(M.U.T.-III display)

Adjusting content

Auto door
unlock

Adjustment of the
auto door unlock
function

Disable

Without function (initial condition)

Always (P pos)

With function: Operates when the shift
lever or the selector lever is moved to the
P position.

Always(Lock pos)

With function: Operates when the ignition
switch is moved to the LOCK (OFF)
position.

DOOR

BODY

42A-51

DOOR ASSEMBLY

REMOVAL AND INSTALLATION

M1423002201112

Post-installation operation
• Door adjustment (Refer to

P.42A-44

.)

ACC00289

ACB05784

5, 6

9

1

2

3

5

6

8

7

10

AB

26 ± 6 N·m

26 ± 6 N·m

25 ± 4 N·m

20 ± 5 N·m

4.0 ± 2.0 N·m

5.0 ± 1.0 N·m

4

<Front door>

Door unlock
mode

Adjustment of
power door locks
with selective
unlocking

All Doors Unlock

Without function: The first operation of
keyless entry system or unlock operation
by KOS unlocks all doors (initial condition).

Dr Door Unlock

With function: The first operation of
keyless entry system or unlock operation
by KOS unlocks the driver's door only, and
the second unlock operation within 2
seconds after that unlocks all doors.

Timer lock timer Timer lock period

adjustment

30 sec

30 seconds (initial condition)

60 sec

60 seconds

120 sec

120 seconds

180 sec

180 seconds

Adjustment
item (M.U.T.-III
display)

Adjustment item

Adjusting content
(M.U.T.-III display)

Adjusting content
