CVT FLUID COOLER AND COOLER LINE
CVT
23A-66
CVT FLUID COOLER AND COOLER LINE
REMOVAL AND INSTALLATION
M1231212500332
Pre-removal and post-installation operation
• Engine room under cover front, engine room side cover
(Refer to GROUP 51
− Under Cover .)
• Engine coolant draining and refilling (Refer to GROUP 14
− On-vehicle Service − Engine Coolant Replacement .)
ACC00442AB
1
2
CVT fluid cooler line removal
steps
1.
Water feed hose
2.
Water return hose
PADDLE SHIFT ASSEMBLY
REMOVAL AND INSTALLATION
M1231213600097
Refer to GROUP 37
− Steering Column Shaft
Assembly .
PADDLE SHIFT SWITCH CHECK
M1231211500317
ACB05424AB
1. Check the continuity between the paddle shift
switch connecter terminals.
Standard value:
Paddle shift lever
Terminal
number
Resistance
value
Upshift and hold the
lever.
3
− 2
Continuity
exists (2
Ω or
less).
Downshift and hold
the lever.
1
− 2
No operation
No continuity between the
terminals.
2. In the cases other than the above, replace the
paddle shift assembly.
