GENERAL INFORMATION

MULTIPOINT FUEL INJECTION (MPI)

13A-4

Control System Diagram

AKB00748AB

Air flow sensor
Intake air temperature
sensor
Throttle position sensor
(main)
Throttle position sensor
(sub)
Manifold absolute
pressure sensor
Inlet camshaft position
sensor
Engine coolant
temperature sensor
Detonation sensor
Crank angle sensor
Oxygen sensor (front)
Oxygen sensor (rear)

1
2

3

4

5

6

7

8
9

10
11

Injector
Inlet oil feeder
control valve
Throttle valve control
servo
Purge control solenoid
valve

1
2

3

4

Power supply
Ignition switch-IG
Ignition switch-ST
Accelerator pedal
position
sensor (main)
Accelerator pedal
position
sensor (sub)
Engine oil pressure
switch
Alternator FR terminal
Alternator L terminal
CAN communication
(input signal)

Engine-
ECU

Ignition coil
Engine control relay
Fuel pump relay
Starter relay
Throttle valve control
servo relay
A/C compressor relay
Alternator G terminal
Oxygen sensor (front)
heater
Oxygen sensor (rear)
heater
CAN communication
(input signal)

4 Throttle position sensor (sub)

3 Throttle valve control servo

4 Purge control solenoid valve

2 Inlet oil feeder control valve

1 Injector

Canister

Air

3 Throttle position sensor (main)

5 Manifold absolute pressure
   sensor

7 Engine coolant
   temperature sensor

8 Detonation sensor

9 Crank angle sensor

10 Oxygen sensor (front)

11 Oxygen sensor (rear)

6 Inlet camshaft
   position sensor

From fuel pump

1 Air flow sensor

2 Intake air
   temperature
   sensor

Catalytic
converter

Barometric
pressure
sensor

Catalytic
converter

Downloaded from

www.Manualslib.com



manuals search engine



CONTROL UNIT

MULTIPOINT FUEL INJECTION (MPI)

13A-5

CONTROL UNIT

M2132021500960

ENGINE-ECU

Engine-ECU is installed in the engine room.
Engine-ECU judges (calculates) the optimum control
to deal with the constant minute changes in driving
conditions based on information input from the sen-
sors and drives the actuator. Engine-ECU is com-
posed of 32-bit microprocessor and Random Access
Memory (RAM), Read Only Memory (ROM) and

Input /Output interface. Engine-ECU uses
flash-memory ROM that allows re-writing of data so
that change and correction of control data is possible
using special tools. It also uses Electrically Erasable
Programmable Read Only Memory (EEPROM) so
that studied compensation data is not deleted even if
battery terminals are disconnected.

ENGINE-ECU CONNECTOR INPUT/OUTPUT PIN ARRANGEMENT

AK602218AD

Microprocessor

RAM

Input
interface

Input
sensor

Output
interface

Output
actuator

ROM

Engine-ECU

AK602565 AB

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

91

90

89

87

86

84

85

83

82

88

92

93

94

95

96

97

98

99

109

108

107

106

105

104

103

102

112

113

114

115

116

117

118

100

101

111

110

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

25

24

23

22

60

59

58

57

56

55

54

53

52

51

50

49

48

47

46

45

44

43

42

63

61

62

64

71

72

73

74

75

76

77

78

79

80

81

Terminal
No.

Terminal
code

Terminal name

Terminal
No.

Terminal
code

Terminal name

1

OCVI

Inlet oil feeder control valve

2

INJ1

No. 1 injector

3

INJ2

No. 2 injector

4

CIL1

No. 1 ignition coil

5

CIL2

No. 2 ignition coil

6

NTSW

Starter active signal

8

SGT

Crank angle sensor

9

5V

Sensor supplied voltage

10

TPSM

Throttle position sensor
(main)

11

TPSS

Throttle position sensor (sub)

Downloaded from

www.Manualslib.com



manuals search engine



CONTROL UNIT

MULTIPOINT FUEL INJECTION (MPI)

13A-6

12

TPS5

Power supply voltage
applied to throttle position
sensor

13

TPSE

Throttle position sensor earth

14

CPI

Inlet camshaft position
sensor

15

ETV+

Throttle valve control servo (+)

16

ETV

−

Throttle valve control servo
(

−)

18

INJ3

No. 3 injector

19

INJ4

No. 4 injector

20

CIL3

No. 3 ignition coil

21

CIL4

No. 4 ignition coil

24

SGTE

Crank angle sensor earth

25

K/S

Detonation sensor (+)

26

WTS

Engine coolant temperature
sensor

27

WTSE

Engine coolant temperature
sensor earth

30

CPIE

Inlet camshaft position sensor
earth

34

OHFL

Oxygen sensor (front) heater 35

OHRL

Oxygen sensor (rear) heater

36

OPSW

Oil pressure switch

37

PURG

Purge control solenoid valve

38

O2FL

Oxygen sensor (front)

39

OFLE

Oxygen sensor (front) offset
voltage

40

O2RL

Oxygen sensor (rear)

41

ORLE

Oxygen sensor (rear) offset
voltage

42

K/SE

Detonation sensor (

−)

44

MAP5

Power supply voltage applied
to manifold absolute pressure
sensor

45

MAP

Manifold absolute pressure
sensor

46

MAPE

Manifold absolute pressure
sensor earth

60

ALTG

Alternator G terminal

61

ALTF

Alternator FR terminal

62

ALTL

Alternator L terminal

71

RSG

Throttle valve control servo
earth

72

RSB

Power supply voltage
applied to throttle valve
control servo

73

C/R

Engine control relay

74

APSM

Accelerator pedal position
sensor (main)

75

APS5

Power supply voltage applied
to accelerator pedal position
sensor (main)

76

APSE

Accelerator pedal position
sensor (main) earth

77

APSS

Accelerator pedal position
sensor (sub)

78

5VV

Power supply voltage
applied to accelerator pedal
position sensor (sub)

79

EV

Accelerator pedal position
sensor (sub) earth

81

GNDE

Engine-ECU earth

82

BAT1

Power source

83

RSH

Throttle valve control servo
earth

84

C/RL

Throttle valve control servo
relay

87

AFS

Air flow sensor

88

AFSE

Air flow sensor earth

89

ATS

Intake air temperature
sensor

90

CANH

CAN interface (high)

Terminal
No.

Terminal
code

Terminal name

Terminal
No.

Terminal
code

Terminal name

Downloaded from

www.Manualslib.com



manuals search engine



SENSOR

MULTIPOINT FUEL INJECTION (MPI)

13A-7

SENSOR

M2132001001472

AIR FLOW SENSOR

Air flow sensor is installed in the air intake hose. Air
flow sensor is composed of an extremely small heat-
sensing resistor. The air flow sensor controls the
amount of electric current flowing into the heat sens-
ing resistor to keep the heat sensing resistor at a

constant temperature to the intake air temperature.
When the air mass flow rate increases, the air flow
speed is higher and also the amount of heat transfer
from the heat sensing resistor to the air increased.
Therefore, the air flow sensor increases the amount
of electric current to the heat sensing resistor. Thus,
the amount of electric current increases in accord-
ance with the air mass flow rate. The air flow sensor
measures the air mass flow rate by detecting the
amount of electric current. The air flow sensor ampli-
fies the detected electric current amount and outputs
it into the engine-ECU. Engine-ECU uses this output
current and engine speed to calculate and decide
basic fuel injection time. Sensor properties are as
shown in the figure.

91

CANL

CAN interface (low)

92

IGN

Ignition switch-IG

93

GNDE

Engine-ECU earth

96

FP/R

Fuel pump relay

97

AFS5

Air flow sensor reference
voltage

102

AC/R

A/C compressor relay

103

FMB

Flash EP-ROM data
rewriting power source

104

BACK

Backup power source

105

ST

Ignition switch-ST

106

STRL

Starter relay

108

BRK

Brake switch

Terminal
No.

Terminal
code

Terminal name

Terminal
No.

Terminal
code

Terminal name

AKB00749AB

Sensing area

Silicon substrate

Heat sensing
resistor

Intake air

Diaphragm

IN

OUT

AKB00757

5V

AB

From engine control relay

Air flow sensor

Engine-ECU

Output current (mA)

Mass flow (g/s)
