VEHICLE IDENTIFICATION

GENERAL

00-10

<2200>

VEHICLES FOR RUSSIA (EASTERN EUROPE COUNTRIES)

<2000>

<2400>

MODEL CODE

Model code

Seating
capacity

Engine model

Transmission model

Fuel supply
system

GF6W

XJHXR6

5-persons

4N14 (2,268 mL)
DOHC Direct
injection-diesel with
intercooled turbocharger
engine, Auto Stop & Go
(AS&G) <Clear Tec
AS&G>

F6MBA (Front wheel
drive 2WD, 6M/T)

Electrical fuel
injection
(Direct
injection-Diesel
engine control
system)

XJHXL6

XJXXL6

7-persons

XLHFZL6

5-persons

4N14 (2,268 mL)
DOHC Direct
injection-diesel with
intercooled turbocharger
engine

W6AJA (Electronic
control 4WD, INVECS-II
6A/T with sport mode)

XLXFZL6

7-persons

XLXFZR6

XJSXZL6

5-persons

4N14 (2,268 mL)
DOHC Direct
injection-diesel with
intercooled turbocharger
engine, Auto Stop & Go
(AS&G) <Clear Tec
AS&G>

W6MBA (Electronic
control 4WD, 6M/T)

XJSXZR6

XJXXZL6

7-persons

XJXXZR6

Model code

Seating
capacity

Engine model

Transmission model

Fuel supply
system

GF2W

XTSHL6Z

5-persons

4B11 (1,998 mL) DOHC
MIVEC petrol engine

F1CJA (Front wheel
drive 2WD, INVECS-III
CVT with sport mode)

MPI

XTSHZL6Z

W1CJA (Electronic
control 4WD, INVECS-III
CVT with sport mode)

Model code

Seating
capacity

Engine model

Transmission model

Fuel supply
system

GF3W

XTHHZL6Z

5-persons

4B12 (2,360 mL) DOHC
MIVEC petrol engine

W1CJA (Electronic
control 4WD, INVECS-III
CVT with sport mode)

MPI

1

2

3

4 5 6 7 8 9

10

ACB04331AB

No. Item

Content

1

Development

GF

OUTLANDER

Downloaded from

www.Manualslib.com



manuals search engine



VEHICLE IDENTIFICATION

GENERAL

00-11

2

Engine type

2

2.0L MPI (4B11) MIVEC

3

2.4L MPI (4B12) MIVEC

6

2.2L Diesel (4N14)

7

2.0L MPI (4J11) Smart MIVEC

3

Vehicle type

W

Station wagon

4

Body style

X

4-door with tailgate

5

Transmission type

J

6M/T

L

6A/T

N

5M/T

T

CVT

6

Trim level (Price class)

H

Vehicles for Europe: H-line <5-seating>

Vehicles for Russia: INVITE <2000>, INSTYLE <2400>

S

Vehicles for Europe: M-line

Vehicles for Russia: INFORM

X

Vehicles for Europe: H-line <7-seating>

7

Engine specification

F

Intercooled turbocharger (DOHC)

H

MIVEC (DOHC)

X

Auto Stop & Go (AS&G) <Clear Tec AS&G>

8

Special feature

None

2WD

Z

4WD

9

Steering wheel location

L

Left handle

R

Right handle

10

Destination

6

Vehicles for Europe

6Z

Vehicles for Russia

No. Item

Content

Downloaded from

www.Manualslib.com



manuals search engine



MAJOR SPECIFICATIONS

GENERAL

00-12

MAJOR SPECIFICATIONS

M2000030003278

VEHICLES FOR EUROPE

<2000>

Item

GF7W

XNSXL6

XTXXL6

Vehicle
dimension mm

Front track

1

1,540

1,540

Overall width

2

1,800

1,800

Front overhang

3

955

955

Wheelbase

4

2,670

2,670

Rear overhang

5

1,030

1,030

Overall length

6

4,655

4,655

Ground clearance (unladen)

7

215

215

Overall height (unladen)

8

1,680

1,680

Rear track

9

1,540

1,540

Vehicle weight
kg

Kerb weight

Without full optional parts 1,380

1,450

With full optional parts

1,469

1,534

Gross vehicle weight

1,985

2,170

Gross axle weight rating-front

1,150

1,150

Gross axle weight rating-rear

1,250

1,250

Gross combination weight

3,665

3,850

Seating capacity

5

7

Engine

Model No.

4J11

4J11

Type

SOHC MIVEC petrol
engine, Auto Stop & Go

SOHC MIVEC petrol
engine, Auto Stop & Go

Total displacement mL

1,998

1,998

Max. output <EEC> kW/rpm

110/6,000

110/6,000

Max. torque <EEC> N

⋅m/rpm

195/4,100

− 4,200

195/4,100

− 4,200

Fuel system

Fuel supply system

MPI

MPI

Transmission

Model code

F5MBB

F1CJA

Type

Front wheel drive 2WD,
5M/T

Front wheel drive 2WD,
INVECS-III CVT with
sport mode

ACB04339AB

1
2

3

4

5

6

7

8

9

Downloaded from

www.Manualslib.com



manuals search engine



MAJOR SPECIFICATIONS

GENERAL

00-13

Turning radius
m

Body

5.73

5.73

Wheel

5.3

5.3

Item

GF7W

XNSXL6

XTXXL6

Item

GF7W

XTHXL6

XTHXZL6

Vehicle
dimension mm

Front track

1

1,540

1,540

Overall width

2

1,800

1,800

Front overhang

3

955

955

Wheelbase

4

2,670

2,670

Rear overhang

5

1,030

1,030

Overall length

6

4,655

4,655

Ground clearance (unladen)

7

215

215

Overall height (unladen)

8

1,680

1,680

Rear track

9

1,540

1,540

Vehicle weight
kg

Kerb weight

Without full optional parts 1,420

1,485

With full optional parts

1,504

1,569

Gross vehicle weight

1,985

2,070

Gross axle weight rating-front

1,150

1,150

Gross axle weight rating-rear

1,250

1,250

Gross combination weight

3,665

3,750

Seating capacity

5

5

Engine

Model No.

4J11

4J11

Type

SOHC MIVEC petrol
engine, Auto Stop & Go

SOHC MIVEC petrol
engine, Auto Stop & Go

Total displacement mL

1,998

1,998

Max. output <EEC> kW/rpm

110/6,000

110/6,000

Max. torque <EEC> N

⋅m/rpm

195/4,100

− 4,200

195/4,100

− 4,200

Fuel system

Fuel supply system

MPI

MPI

Transmission

Model code

F1CJA

W1CJA

Type

Front wheel drive 2WD,
INVECS-III CVT with
sport mode

Electronic control 4WD,
INVECS-III CVT with
sport mode

Turning radius
m

Body

5.73

5.73

Wheel

5.3

5.3
