HOW TO USE THIS MANUAL

GENERAL

00-2

HOW TO USE THIS MANUAL

M2000029001706

MODEL INDICATIONS

The following abbreviations are used in this manual
for identification of model types.
2000:Indicates models equipped with the 1,998 mL

<4B11, 4J11> petrol engine.

2200:Indicates models equipped with the 2,268 mL

<4N14> diesel engine.

2400:Indicates models equipped with the 2,360 mL

<4B12> petrol engine.

2WD:Indicates the 2-wheel drive vehicles.
4WD:Indicates the 4-wheel drive vehicles.
A/C:Indicates the air conditioner.

A/T:Indicates the automatic transmission, or models

equipped with the automatic transmission.

CVT: Indicates the continuously variable transmis-

sion.

DOHC: Indicates an engine with the double over-

head camshaft.

INVECS:Indicates the intelligent and innovative vehi-

cles electronic control system.

MIVEC:Indicates the Mitsubishi innovative valve tim-

ing electronic control system.

MPI:Indicates the multipoint injection.
M/T:Indicates the manual transmission, or models

equipped with the manual transmission.

SOHC:Indicates the single overhead camshaft.

TARGETS OF DEVELOPMENT

M2000004002315

Global demand for car production is expected to
recover and increase further in the future. Due to this
trend, the demand for SUV will also increase stably.
A middle-size segment still accounts for 40% of all
SUVs. Furthermore, emerging markets are also
expected to expand drastically. By considering these
market trends, Mitsubishi Motors launches "NEW
OUTLANDER", which leads with its innovations in
the areas of fuel consumption and environmental
protection (low CO

2

 emission level), in all the mar-

kets (including major advanced and emerging coun-
tries).

MAIN CONCEPT: WELL BALACNED ECO
SUV

Enhancement of actual fuel consumption & Per-
ceived Quality to get well balanced SUV

• Eco friendliness boasting of top class low fuel

consumption and CO2 emission

• Excellent safety performance

• High-quality and convenient interior and comfort

equipment

PRODUCT FEATURES

M2000005001207

EVOLVED ORTHODOXY SUV

UPPER CLASS QUALITY & CRAFTSMAN-
SHIP

Perceived quality

• The interior has been designed that customers

can feel PERCEIVED QUALITY when they open
the door and get in the car.

Quietness and comfortable cabin

• Pendulum mount structure for New OUTLANDER

to reduce the engine vibration and the noise.

• NEW low acoustic noise tyre is available.

• Enhancement of noise isolation performance.

• Special treatment to reduce wind noise at A-pillar,

door mirror and weatherstrip moulding.

Enhancement of field of vision

• Wide front and side views by optimized A-pillar

shape & component layout, low wiper rest posi-
tion and washer nozzle mounted under the rear
edge of the hood.

LONG CARGO SPACE WITH EASY SEAT
ARRANGEMENT

Long cargo space with convenient luggage box

• Best length in class at cargo space.

• Convenient luggage box is available for Instyle

and Ultimate.

Long and flat cargo space

• Easy double action folding 2nd seats.

Downloaded from

www.Manualslib.com



manuals search engine



TECHNICAL FEATURES

GENERAL

00-3

• Long and flat cargo space (with luggage box) +

335 mm in comparison with current model.

ENHANCEMENT OF ACTUAL FUEL
CONSUMPTION

Effective major items to enhance fuel economy &

CO2 emission

• Low-resistance tyre used (Rolling resistance

-10%).

• Enhancement of aerodynamics Cd: 0.33 (current

OUTLANDER: 0.36).

• Weight reduction (- 85 kg from current OUT-

LANDER).

Advanced Electric AWC control

• NEW "4WD ECO" mode enhances fuel economy

with dynamic stability.

Advanced equipment

• Electric power tailgate.

• Dual-zone air conditioner.

• New-generation navigation system.

• Display audio with rear view camera.

• OSS (One-push Start Switch) & KOS (Keyless

Operation System).

• Tilt & telescopic steering wheel.

TECHNICAL FEATURES

EXTERIOR

M2000017001884

DESIGN FEATURES

Design theme: Next generation environmental
friendly SUV, connecting people and nature.

• "Environment Initiative Design" matching new

era.

• "Quality Design" providing good presence and

higher class.

• "Advanced Design" showing a sense of high

practicality and high safety performance.

Mode type

Explanation

4WD ECO

2WD at normal situation for fuel
economy and turns to 4WD due to
road condition automatically.

4WD AUTO

Same as current.

4WD LOCK

Same as current.

Downloaded from

www.Manualslib.com



manuals search engine



TECHNICAL FEATURES

GENERAL

00-4

MAIN FEATURES

1. FRONT DESIGN

• Wide and stable image due to the combina-

tion of horizontal graphic and trapezoid grille.

2. SIDE DESIGN

• Decent shape (boxy silhouette) shows relia-

ble and practical image.

• Aerodynamic body shape due to tuned roof-

line, narrowed-down side surface of cabin and
edge characters on corners.

• Lighter body due to rich tensioned surfaces

which helps to attain rigidity. (The form itself
create rigidity.)

• Bold and grand image due to main character

line stretched from front to rear makes the car
look bigger than actual size.

• Dynamic and going-forward image due to

wedged character line.

3. REAR DESIGN

• Wide and nimble image due to high-posi-

tioned horizontal graphic.

ACC00047

ACB05806

AC

2

2

3

1

Downloaded from

www.Manualslib.com



manuals search engine



TECHNICAL FEATURES

GENERAL

00-5

INTERIOR
