INSTRUMENT PANEL AND FLOOR CONSOLE

INTERIOR

52A-3

INSTRUMENT PANEL AND FLOOR CONSOLE

M2520001001462

The instrument panel offers the following features:

• The division unit of each part has been enlarged,

also the gap and level difference between the
instrument panel has been minimised to achieve
the delicate quality.

ACC00465

Key box

AB

Front floor console

Rear floor console

Console cup holder

Armrest

Instrument centre panel

Decoration panel

Key box

Console cup holder

Accessory
socket

USB adapter

 Glove box assembly

SEAT

INTERIOR

52A-4

• A lamp has been added to the large-sized glove

box with card holder have been installed for the
improved convenience.

• To the lower part of centre panel, a centre lower

tray that can store up to 6 CDs has been installed
with which jumping out or dropping of stored
items during abrupt start is prevented.

• A console cup holder that can store two plastic

bottles or brick packs has been installed in the
front floor console.

• Rear console tray that can store a mobile phone,

cards, pens, and others has been installed to the
rear floor console, and additionally, rear floor con-
sole box that can store 10 CDs or 7 DVDs has
been installed to under the rear floor console.

• Simple and clear form by reducing separations on

the instrument panel.

• Soft pads attached around the upper part, thus

improving the sense of touch.

• Ergonomic layout where controls are arranged at

the centre of the dash board and face towards
the driver.

• High grossed black finish on the instrument cen-

tre panel.

• Decoration panels, which underline sportiness

(silver carbon) or luxury (wood grain tone), are
arranged optimally in the vicinity of front passen-
ger. <wood grain tone: optional equipment>

• The engine can be started and power supply to

accessories can be turned on and off in the con-
ventional manner by inserting a keyless operation
key into the key slot on the instrument panel cen-
tre lower (upper part of the front floor console).

SEAT

FRONT SEAT

M2520004001494

The front seat offers the following advantages:

• The seats are designed to be adjustable in the

reclining and sliding directions.

• Headrestraints with a vertical adjustment mecha-

nism have been adopted.

• The seat height adjustment function has been

introduced to the driver’s seat. This function
raises and lowers the seat cushion together with
the seatback, thus the driver's waist position in
relation to the seatback is always kept constant,

ACB05051 AB

Seatback pocket

Headrestraint

Seatback
frame

Cross frame

<Front/rear collision protection seat
mechanism>

Headrestraint
adjustment

Reclining adjustment

Height adjustment

Slide adjustment

SEAT

INTERIOR

52A-5

resulting in the improved riding comfort. By the
height adjustment amount up to 45 mm, the more
optimised driving position can be adjusted. The
pump type seat height adjustment lever has been
adopted for convenient use.

• For the driver's seat, 4 WAY power seat has been

adopted for better convenience. <Vehicles with
power seat>

• The driver's seat and passenger's seat have

seatback pockets for better convenience.

• The frontal and rear-end collision protection seat

structure (backward layout of seatback frame and
optimisation of headrestraint position) has been
adopted to enhance safety during a collision at
lower vehicle speed. The cross frame has been
installed below the seat cushion to reduce the for-
ward travel distance of the passengers during a
frontal collision and has enhance safety.

• Glared fabric has been newly developed based

on fine and high-quality fabric has been adopted,
thus offering tailor-made smoothness.

• Lateral holding of the seatback has been

improved.

• The head restraints is in height than the prede-

cessor, thus enhancing safety.

• The heated seat switch is relocated from the seat

to the front floor console, thus improving ease of
operation. <Vehicles with heated seats>

SECOND SEAT

M2520005000353

The second seats offer the following features.

ACC00464 AB

<Dual-action folding structure>


Reclining
adjustment

Cup holder

: ISO-FIX child seat fixing bar positions
: Tether anchorage positions

Dual-action
folding structure

SEAT

INTERIOR

52A-6

• The dual-action folding mechanism of the second

seat allows to flip up the seat cushion and then
fold the seatback with easy operation. Due to
this, a lowered flat cargo space can be achieved
without any compromise to seating comfort.

• Reclining adjustment mechanisms have been

adopted to improve comfort.

• Armrests with a cup holder have been installed to

improve convenience.

• Headrestraints have been installed to the second

seats.

• The ISO-FIX child seat fixing bar is installed as

standard on the outer seats, and the tether
anchorage on outer seats, improving the versatil-
ity of child seat installation.

• The structure of the second seat frame has been

optimised and the centre seat belt retractor is
mounted on the roof, thus reducing its weight.
