LOCATION OF SYNTHETIC-RESIN PARTS

SYNTHETIC-RESIN PARTS

5-3

No.

Part Name

Name Of Resin

Abbreviat
ion

Heat-resis
tant Temp
[

°C ]

1

Door mirror outer cover (colour)

Acrylonitrile butadiene styrene

ABS

80

2

Tailgate garnish

3

Radiator grille

Acrylonitrile styrene acrylate

ASA

80

4

Door mirror outer cover (black)

5

Headlamp

Polycarbonate

PC

120

6

Door outside handle

Polycarbonate+Polyethylene
terephthalate

PC+PET

120

7

Front roof rail cover

8

Rear roof rail cover

9

Rear splash shield

Polyethylene terephthalate+Allyl
chloride

PET+AC

80

10

Rear wiper arm assembly

Glass fibre reinforced polyethylene
terephthalate (45%)

PET-GF45 80

11

Shift lever panel assembly

Polyoxymethylene

POM

80

12

Front door sash trim

Polypropylene

PP

80

13

Inside rear view mirror

14

Quarter trim lower

15

Rear end trim

16

Tailgate upper trim

17

Tailgate opening side trim

18

Rear splash shield

19

Rear scuff plate

20

Front scuff plate

21

Cowl side trim

22

Front splash shield

23

Front bumper lamp hole cover

Rubber modified polypropylene

PP+E/P

80

24

Front fog lamp bezel

25

Front bumper face

26

Radiator grille

27

Rear bumper face

28

Rear mud guard

29

Side air dam

30

Front door trim

Talc filled polypropylene (10%)

PP-TD10

110

− 120

31

Centre pillar trim lower

32

Rear door trim

33

Tailgate trim

34

Front pillar trim

Talc filled rubber modified
polypropylene (15%)

PP+E/P-T
D15

80

LOCATION OF SYNTHETIC-RESIN PARTS

SYNTHETIC-RESIN PARTS

5-4

NOTE:

.

•

A slash (/) in the material symbol indicates that two different materials make two-layer construction. A plus
sign (+) indicates that the two different materials mix each other.

•

The indicated heat-resistant temperature for parts which are composed of two or more types of material is
the value for the material with the lowest heat-resistant temperature.

•

The material symbols for synthetic-resin parts are embossed on the parts in hidden places.

35

Front deck garnish

Talc filled polypropylene (20%)

PP-TD20

120

− 130

36

Instrument panel

37

Centre pillar trim upper

38

Quarter trim upper

39

Rear console

40

Roof drip moulding assembly

Thermoplastic elastomer

TPO

80

− 100

No.

Part Name

Name Of Resin

Abbreviat
ion

Heat-resis
tant Temp
[

°C ]

6-1

GROUP 6

BODY COLOUR

CONTENTS

BODY COLOUR CODE . . . . . . . . . . .

6-2

BODY COLOUR CHARTS. . . . . . . . .

6-2

BODY COLOURING  . . . . . . . . . . . . .

6-3

FRONT END . . . . . . . . . . . . . . . . . . . . . . . .

6-3

WHEELHOUSE . . . . . . . . . . . . . . . . . . . . . .

6-3

FRONT BUMPER  . . . . . . . . . . . . . . . . . . . .

6-4

REAR BUMPER  . . . . . . . . . . . . . . . . . . . . .

6-4

BODY COLOUR CODE

BODY COLOUR

6-2

BODY COLOUR CODE

M4060001001382

Body colour code is stamped on the vehicle informa-
tion code plate, which is attached on the hood.

BODY COLOUR CHARTS

M4060002004049

Check the vehicle’s body colour code, and then use
this body colour chart to determine the refinishing
paint supplier from which the colour can be pur-
chased.

NOTE:

.

•

The coating film structure indicates top coating only (2S: 2 coat solid, 2M: 2 coat metallic, 2P: 2 coat pearl,
3P: 3 coat pearl).

•

For painting, inner panel colours should be similar to the outer panel colours.

•

The roof rail is coated in Black (AC10657).

AC905413

ABA00001AB

Body colour code

Colour

Colour
code

Colour
number

Colour name

Coating film
structure

Composition of film

SILVER

A31

CMA10031

Cool Silver Metallic

2M

Metallic

REDDISH BROWN

C07

CMC10007 Copper Metallic

2M

Metallic

DARK BLUE

D14

CMD10014 Cosmic Blue Mica

2P

Interferenced Pearl

GREY

U17

CMU10017 Titanium Grey Metallic

2M

Metallic

BLUISH SILVER

U21

CMU10021 Technical Silver Metallic 2M

Metallic

WHITE

W13

CMW10013 White Pearl

3P

Pearl

WHITE

W37

CMW10037 White Solid

2S

Solid

BLACK

X42

AC11342

Black Mica

2P

Interferenced Pearl
