TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-14

SIDE BODY

M4020007001397

ABB00693AB

30

ABB00695AB

33

ABB00696AB

34

35

34, 35

ABB00697AB

36

37

36, 37

ABB00698AB

38

ABB00699AB

39

ABB00680

Unit: mm

41

46

45

40

44

49

43

48

42

47

770

1115

677

1126

746

1232

713

1163

869

867

758

878

986

AB

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-15

ABB00681AB

46

42

51

54

53

52

50

1117

1067

1122

1197

951

716

410

378

897

988

Unit: mm

No.

Standard measurement point

Hole shape

Size mm

40

Front pillar positioning notch

−

−

41

Front pillar positioning notch

−

−

42

Roof side rail positioning notch

−

−

43

Side sill positioning notch

−

−

44

Centre pillar positioning notch

−

−

45

Centre pillar positioning notch

−

−

46

Roof side rail positioning notch

−

−

47

Side sill positioning notch

−

−

48

Quarter panel positioning notch

−

−

49

Quarter panel positioning notch

−

−

50

Centre of front door upper hinge mounting hole

Round

11

51

Centre of front door lower hinge mounting hole

Round

11

52

Centre of rear door upper hinge mounting hole

Round

11

53

Centre of rear door lower hinge mounting hole

Round

11

54

Centre of rear door switch mounting hole

Round

5

ABB00703

40

AB

ABB00704AB

41

51

41, 51

ABB00705AB

42

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-16

ABB00706AB

43

ABB00707AB

44

ABB00708AB

45

53

45, 53

ABB00709AB

46

48

46, 48

ABB00711AB

47

ABB00712AB

49

ABB00730 AB

50

ABB00731AB

52

ABB00732 AB

54

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-17

REAR BODY

M4020008001367

ABB00733AB

61

60

62

56

55

59

58

730

1073

762

1545

614

1120

272

1166

1056

1042

724

1307

1056

1314

1417

1175

Unit: mm

ABB00733

AB

61

60

57

693

1166

1308

1115

111

Unit: mm

No.

Standard measurement point

Hole shape

Size mm

55

Centre of tailgate hinge mounting hole

Round

12

56

Centre of tailgate gas spring assembly mounting hole

Round

9

57

Centre of rear combination lamp assembly mounting hole

Square

8.5

58

Centre of rear combination lamp assembly mounting hole

Round

8

59

Centre of rear bumper assembly mounting hole

Round

7
