Mitsubishi Outlander. Body repair manual - part 15





HEADLAMP SUPPORT

WELDED PANEL REPLACEMENT

3-3

NOTES

FENDER SHIELD

WELDED PANEL REPLACEMENT

3-4

 FENDER SHIELD

M4030004000374

AB300048

Spot welding

MIG plug welding      : indicates two panels to be welded
                                  : indicates three panels to be welded

MIG spot welding

MIG arc welding (continuous)

Braze welding

Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded joints.)

(                                                               )

Symbol

Operation description

AB300048

Spot welding

MIG plug welding      : indicates two panels to be welded
                                  : indicates three panels to be welded

MIG spot welding

MIG arc welding (continuous)

Braze welding

Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded joints.)

(                                                               )

Symbol

Operation description

AC

AB301579

AB202357

A

E

A

AB

REPAIR WELDS

High rigidity
foam

CAUTION

When repairing the area using foam materials do not use firing tools since the foaming materials may

burn.
NOTE:

.

Refer to the Headlamp Support section on

P.3-2

 for the welding point with headlamp support.

Refer to the Front Pillar section on

P.3-12

 for the welding points with the upper frame extension outer.

AB200555

B

B

C

D

F

G

D

AB

(With the upper frame extension outer removed)

C

FENDER SHIELD

WELDED PANEL REPLACEMENT

3-5

AB301580

AB200641

AB301143

E

F

I

G

H

H

I

I

AB

(Left side)

(Right side)

10 points
right side

FENDER SHIELD

WELDED PANEL REPLACEMENT

3-6
