SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-245

DIAGNOSTIC PROCEDURE

Step 1. Connector check: A-29 <front RH> or
A-16 <front LH> front turn-signal lamp connector,
A-01 <side RH> or A-04 <side LH> side
turn-signal lamp connector, D-14 <rear RH> or
D-19 <rear LH> rear combination lamp connector,
C-05 <turn-signal indicator lamp> and C-04
<turn-signal indicator lamp (LH)> combination
meter connector

AC308678

A-29(B)

2 1

A-29

5

6

3 2

4

1

A-01

A-01(GR)

AB

Connectors: A-01, A-29

Harness side

<LHD>

AC308685

A-29(B)

2 1

A-29

5

6

3 2

4

1

A-01

A-01(GR)

AB

Connectors: A-01, A-29

Harness side

<RHD>

AC308680

A-16(B)

AB

2 1

A-16

5

6

3 2

4

1

A-04

A-04(GR)

Connectors: A-04, A-16

Harness side

<LHD>

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-246

AC308687

A-16(B)

AB

2 1

A-16

5

6

3 2

4

1

A-04

A-04(GR)

Connectors: A-04, A-16

Harness side

<RHD>

AC308717

Connectors: C-04, C-05

AE

C-04

C-05

G

G

22

11

5

16

19

20

21

17

18

8

10 9

7 6

13

1514

12

2

4 3

1

C-04

G

G

52

41

35
46

49

50

51

47

48

38

4039

3736

43

4544

42

32

3433

31

C-05(L)

Harness side

<LHD>

AC308770

Connectors: C-04, C-05

AC

C-04

C-05

C-04

C-05(L)

Harness side

<RHD>

AC308784

Connectors: D-14, D-19

1
3

4

5

2
6

AD

D-14

1
3

4

5

2
6

D-19

Harness side

D-19

D-14

<LHD>

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-247

Q: Is the check result normal?

YES :

Go to Step 2.

NO :

Repair the defective connector.

Step 2. Check the bulb(s) of the turn-signal lamps
or the turn-signal indicator lamps.

Check the bulb(s) of the defective lamp.

Q: Is the check result normal?

YES :

Go to Step 3.

NO :

Replace the bulb(s) of the defective lamp.

AC308788

Connectors: D-14, D-19

1
3

4

5

2
6

AD

D-14

1
3

4

5

2
6

D-19

Harness side

D-19

D-14

<RHD>

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-248

Step 3. Measure the resistance at the A-29 <front
RH> or A-16 <front LH> front turn-signal lamp
connector, the A-01 <side RH> or A-04 <side LH>
side turn-signal lamp connector, the D-14 <rear
RH> or D-19 <rear LH> rear combination lamp
connector, the C-05 <turn-signal indicator lamp>
and C-04 <turn-signal indicator lamp (LH)>
combination meter connector.

AC308678

A-29(B)

2 1

A-29

5

6

3 2

4

1

A-01

A-01(GR)

AB

Connectors: A-01, A-29

Harness side

<LHD>

AC308685

A-29(B)

2 1

A-29

5

6

3 2

4

1

A-01

A-01(GR)

AB

Connectors: A-01, A-29

Harness side

<RHD>

AC308680

A-16(B)

AB

2 1

A-16

5

6

3 2

4

1

A-04

A-04(GR)

Connectors: A-04, A-16

Harness side

<LHD>
