SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-165

DIAGNOSTIC PROCEDURE

Step 1. Connector check: B-07 windshield wiper
motor connector

Q: Is the check result normal?

YES :

Go to Step 2.

NO :

Repair the connector.

Step 2. Check the windshield wiper motor
assembly.

Refer to GROUP 51

−

 Windshield wiper

P.51-22

.

Q: Is the check result normal?

YES :

Go to Step 3

NO :

Replace the windshield wiper motor
assembly.

Step 3. Measure the voltage at the B-07
windshield wiper motor connector.

(1) Disconnect the connector, and measure at the

wiring harness side.

(2) Ignition switch: ACC

AC308694

Connector: B-07 <2000>

B-07(GR)

AE

Harness side

4

1

2

5

3

AC308708

Connector: B-07 <2400 LHD>

B-07(GR)

AF

Harness side

4

1

2

5

3

AC308710

Connector: B-07
<2400 RHD>

B-07(GR)

AB

Harness side

4

1

2

5

3

AC308694

Connector: B-07 <2000>

B-07(GR)

AE

Harness side

4

1

2

5

3

AC308708

Connector: B-07 <2400 LHD>

B-07(GR)

AF

Harness side

4

1

2

5

3

AC308710

Connector: B-07
<2400 RHD>

B-07(GR)

AB

Harness side

4

1

2

5

3

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-166

(3) Check the voltage between the B-07 windshield

wiper motor connector terminal No.2 and body
earth.

OK: System voltage

Q: Is the check result normal?

YES :

Go to Step 5.

NO :

Go to Step 4.

Step 4. Check the wiring harness between B-07
windshield wiper motor connector terminal No.2
and ignition switch (ACC).

4

1

2

5

3

AC301636

Connector B-07
(Harness side)

AB

AC308694

Connector: B-07 <2000>

B-07(GR)

AE

Harness side

4

1

2

5

3

AC308708

Connector: B-07 <2400 LHD>

B-07(GR)

AF

Harness side

4

1

2

5

3

AC308710

Connector: B-07
<2400 RHD>

B-07(GR)

AB

Harness side

4

1

2

5

3

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-167

NOTE:

Prior to the wiring harness inspection, check the
junction connectors C-202, C-203, the intermediate
connectors C-104 and C-106, and repair if
necessary.

•

Check the power supply line to ignition switch
(ACC) for open circuit.

AC308719

Connector: C-104, C-106
<LHD>

C-104(B)

AC

C-104

15

1
8

3

10

2
9

11

4

13

12

5

14

16

7

6

C-106(GR)

C-106

AC308736

Connector: C-104, C-106
<RHD>

C-104(B)

AD

C-104

15

1
8

3

10

2
9

11

4

13

12

5

14

16

7

6

C-106(GR)

C-106

AC308721

Connectors: C-202, C-203

AC

Junction block (Front view)

C-202

C-203

Harness side

C-203

C-202

4

6 5

3

2

1

10

1

6

14

5

12

13

4

11

7

2

3

8

9

<LHD>

Harness side

AC308773

Connectors: C-202, C-203

AC

Junction block (Front view)

C-202

C-203

Harness side

C-203

C-202

4

6 5

3

2

1

10

1

6

14

5

12

13

4

11

7

2

3

8

9

<RHD>

Harness side

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-168

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

Step 5. Connector check: A-12X front-ECU
connector

Q: Is the check result normal?

YES :

Go to Step 6.

NO :

Repair the connector.

Step 6. Check the wiring harness between B-07
windshield wiper motor connector terminal No.3
<L.H. drive vehicles> or terminal No.1 <R.H. drive
vehicles> and A-12X front-ECU connector
terminal No.29.

AC301515 AE

Connector: A-12X

24

29

30

31

2827

25

26

21

2322

Relay box side

AC301515 AE

Connector: A-12X

24

29

30

31

2827

25

26

21

2322

Relay box side

AC308694

Connector: B-07 <2000>

B-07(GR)

AE

Harness side

4

1

2

5

3

AC308708

Connector: B-07 <2400 LHD>

B-07(GR)

AF

Harness side

4

1

2

5

3

AC308710

Connector: B-07
<2400 RHD>

B-07(GR)

AB

Harness side

4

1

2

5

3
