Mitsubishi Outlander (2003+). Manual - part 467

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-157

Step 6. Check the wiring harness between B-07
windshield wiper motor connector terminal No.5
and body earth.

NOTE:

Prior to the wiring harness inspection, check the
junction connector C-17 <L.H. drive vehicles>, and
repair if necessary.

•

Check the earth wires for open circuit.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

Step 7. Connector check: A-12X front-ECU
connector

Q: Is the check result normal?

YES :

Go to Step 8.

NO :

Repair the connector.

AC308694

Connector: B-07 <2000>

B-07(GR)

AE

Harness side

4

1

2

5

3

AC308708

Connector: B-07 <2400 LHD>

B-07(GR)

AF

Harness side

4

1

2

5

3

AC308710

Connector: B-07
<2400 RHD>

B-07(GR)

AB

Harness side

4

1

2

5

3

AC308718

Connector: C-17 <LHD>

AF

C-17(GR)

5

4

3

2

1

13

12

11

10

9

8

7

6

AC301515 AE

Connector: A-12X

24

29

30

31

2827

25

26

21

2322

Relay box side

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-158

Step 8. Measure the voltage at the A-12X
front-ECU connector.

(1) Remove the front-ECU, and measure at the relay

box side.

(2) Ignition switch: ACC

(3) Check the voltage between the A-12X front-ECU

connector terminal No.28 and body earth.

OK: System voltage

Q: Is the check result normal?

YES :

Go to Step 10.

NO :

Go to Step 9.

Step 9. Check the wiring harness between A-12X
front-ECU connector terminal No.28 and the
ignition switch (ACC).

AC301515 AE

Connector: A-12X

24

29

30

31

2827

25

26

21

2322

Relay box side

24

29

30

31

2827

25

26

21

2322

AC301473

Connector A-12X
(Relay box side)

AB

AC301515 AE

Connector: A-12X

24

29

30

31

2827

25

26

21

2322

Relay box side

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-159

NOTE:

Prior to the wiring harness inspection, check the
junction block connectors C-202, C-203 and
intermediate connector C-116 and repair if
necessary.

•

Check the power supply line to the ignition switch
(ACC) for open circuit.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

AC308716

AL

9

21

33

35

24

12

3 4

7

8

5 6

39

28

41

30

18

4243

31

1920

32

40

29

1617

38

27

15

37

36

26

14

13

25

2

1

34

23

11

10

22

Connector: C-116

<LHD>

AC308735

AK

9

21

33

35

24

12

3 4

7

8

5 6

39

28

41

30

18

4243

31

1920

32

40

29

1617

38

27

15

37

36

26

14

13

25

2

1

34

23

11

10

22

C-116

C-116

Connectors; C-116
<RHD>

AC308721

Connectors: C-202, C-203

AC

Junction block (Front view)

C-202

C-203

Harness side

C-203

C-202

4

6 5

3

2

1

10

1

6

14

5

12

13

4

11

7

2

3

8

9

<LHD>

Harness side

AC308773

Connectors: C-202, C-203

AC

Junction block (Front view)

C-202

C-203

Harness side

C-203

C-202

4

6 5

3

2

1

10

1

6

14

5

12

13

4

11

7

2

3

8

9

<RHD>

Harness side

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-160

Step 10. Connector check: C-310 column switch
connector

Q: Is the check result normal?

YES :

Go to Step 11.

NO :

Repair the connector.

Step 11. Check the wiring harness between C-310
column switch connector terminal No.8 and
A-12X front-ECU connector terminal No.26.

NOTE:

Prior to the wiring harness inspection, check the
intermediate connector C-116 and repair if
necessary.

•

Check the wiper backup circuit.

AC308724

Connector: C-310

AB

Harness side

10

5

6

7

9 8

3

4

2 1

<LHD>

AC308778

Connector: C-310

AB

Harness side

10

5

6

7

9 8

3

4

2 1

<RHD>

AC308724

Connector: C-310

AB

Harness side

10

5

6

7

9 8

3

4

2 1

<LHD>

AC308778

Connector: C-310

AB

Harness side

10

5

6

7

9 8

3

4

2 1

<RHD>

AC308716

AL

9

21

33

35

24

12

3 4

7

8

5 6

39

28

41

30

18

4243

31

1920

32

40

29

1617

38

27

15

37

36

26

14

13

25

2

1

34

23

11

10

22

Connector: C-116

<LHD>

AC308735

AK

9

21

33

35

24

12

3 4

7

8

5 6

39

28

41

30

18

4243

31

1920

32

40

29

1617

38

27

15

37

36

26

14

13

25

2

1

34

23

11

10

22

C-116

C-116

Connectors; C-116
<RHD>
