STABILIZER BAR TSB Revision REAR SUSPENSION 34-9 STABILIZER BAR REMOVAL AND INSTALLATION M1341001300123 CAUTION *: Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on INSTALLATION SERVICE POINT . >>A<< STABILIZER BAR MOUNTING BOLT AND NUT rubber bushings by the order and the specified direction as 2. Install the nut on the stabilizer bar mounting bolt to the specified dimensions. Standard value (A): 15 − 17 mm (0.6 − 0.7 inch) AC309535 AB 216 - 245 N·m* 159 - 181 ft-lb* 34 N·m 2 3 6 7 5 6 5 8 1 4 REMOVAL STEPS 1. SHOCK ABSORBER MOUNTING BOLT (LOWER SIDE ONLY) 2. BRACKET >>A<< 4. STABILIZER BAR MOUNTING BOLT AND NUT 5. JOINT CUP REMOVAL STEPS (Continued) AC004232 AB A JOINT COLLAR STABILIZER JOINT CUP MOUNTING RUBBER BOLT AND NUT BUSHING JOINT CUP RUBBER JOINT CUP |
