ON-VEHICLE SERVICE
TSB Revision
WHEEL AND TIRE
31-7
ON-VEHICLE SERVICE
TIRE INFLATION PRESSURE CHECK
M1311000900378
NOTE: For information on tire inflation pressure, refer to the
label attached to the center pillar at the driver's side.
TIRE WEAR CHECK
M1311001000390
Measure the tread depth of the tires.
Minimum limit: 1.6 mm (0.06 inch)
If the remaining tread depth is less than the minimum limit,
replace the tire.
NOTE: When the tread depth of the tires is reduced to 1.6 mm
(0.06 inch) or less, wear indicators will appear.
WHEEL RUNOUT CHECK
M1311001100416
Jack up the vehicle so that the wheels are clear of the floor.
While slowly turning the wheel, measure wheel runout with a
dial indicator.
Limit:
Radial runout: 1.0 mm (0.04 inch) or less
Lateral runout: 1.0 mm (0.04 inch) or less
If wheel runout exceeds the limit, replace the wheel.
ACX00651AB
LATERAL
RADIAL
