AUTOMATIC TRANSMISSION DIAGNOSIS
TSB Revision
AUTOMATIC TRANSMISSION
23A-413
ACTUATOR TEST REFERENCE TABLE
M1231101000121
INVECS-II CANCEL COMMAND
M1231109300115
MUT-III
SCAN TOOL
DISPLAY
ITEM
NO.
INSPECTION ITEM
TEST CONTENT
INSPECTION
REQUIREMENT
NORMAL
CONDITION
2ND SOL
03
Second solenoid valve
Drive the solenoid
valve specified by
the scan tool
MB991958
(MUT-III sub
assembly) at 50%
duty for five
seconds. No other
solenoid valve
should be
energized.
• Ignition switch:
ON
• Transmission
range: P
• Engine:
stopped
• Throttle
opening
voltage: Less
than one volt
The solenoid
should click when
activated
A/T RELAY
12
A/T control relay
Actuator test in
scope mode, data
list No.54. Control
relay is OFF for
three seconds.
Data list No.54
• During test: 0 V
• Normal:
Battery positive
voltage [12 V]
L/R SOL
01
Low-reverse solenoid
valve
Drive the solenoid
valve specified by
the scan tool
MB991958
(MUT-III sub
assembly) at 50%
duty for five
seconds. No other
solenoid valve
should be
energized.
The solenoid
should click when
activated
O/D SOL
04
Overdrive solenoid
valve
TCC SOL
06
Torque converter clutch
solenoid valve
U/D SOL
02
Underdrive solenoid
valve
MUT-III
SCAN TOOL
DISPLAY
ITEM
NO.
ITEM
CONTENT
REMARKS
Std. SIFT
PATN
14
Standard
shift pattern
Stops the INVECS-II
control and shifts
gears according to
the standard shift
pattern.
Use this function when performing procedure 8 in
the road tests. (Refer to
The INVECS-II cancel command will last until the
ignition switch is turned from "ON" to "LOCK"
(OFF) or vice versa.
