AUTOMATIC TRANSMISSION DIAGNOSIS TSB Revision AUTOMATIC TRANSMISSION 23A-169 STEP 44. Measure the transmission range switch output (1) Do not disconnect connector C-92. (4) Measure the voltage between terminal 122 and ground by backprobing. • The voltage should measure battery positive voltage. (5) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 13. AC202317 PCM 120 107 119 106 129 130 118 105 117 114115116 126127128 104 111 103 112 108 101102 109110 121122123 124 113 125 CONNECTOR: C-92 C-92 (GR) AB AC001908AJ C-92 HARNESS CONNECTOR: |
