AUTOMATIC TRANSMISSION DIAGNOSIS
TSB Revision
AUTOMATIC TRANSMISSION
23A-33
2ND GEAR
1
2
3
4
5
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
R N
P
D
3
2
L
: LINE PRESSURE
: OIL PUMP SUCTION PRESSURE
: TORQUE CONVERTER CLUTCH
PRESSURE
: TORQUE CONVERTER AND LUBRICATION
PRESSURE
: TORQUE CONVERTER CLUTCH SOLENOID
VALVE PRESSURE
1. REVERSE
CLUTCH
2. LOW-REVERSE
BRAKE
3. SECOND
BRAKE
4. UNDERDRIVE
CLUTCH
5. OVERDRIVE
CLUTCH
6. ACCUMULATOR
7. CHECK
BALL
8. TORQUE
CONVERTER
CLUTCH
9. FAIL SAFE VALVE A
10. FAIL SAFE VALVE B
11. TORQUE CONVERTER CLUTCH CONTROL
VALVE
12.
SWITCH
VALVE
13. A/T FLUID COOLER
14.
LUBRICATION
15. LOW-REVERSE PRESSURE CONTROL VALVE
16. SECOND PRESSURE CONTROL VALVE
17. UNDERDRIVE PRESSURE CONTROL VALVE
18. OVERDRIVE PRESSURE CONTROL VALVE
19. TORQUE CONVERTER CLUTCH SOLENOID
VALVE
20. LOW-REVERSE SOLENOID VALVE
21.
SECOND
SOLENOID
VALVE
22. UNDERDRIVE SOLENOID VALVE
23. OVERDRIVE SOLENOID VALVE
24. TORQUE CONVERTER PRESSURE
CONTROL VALVE
25.
REGULATOR
VALVE
26.
MANUAL
VALVE
27.
OIL
FILTER
28.
OIL
PUMP
29.
OIL
STRAINER
30.
RELIEF
VALVE
31.
OIL
PAN
