GENERAL DESCRIPTION TSB Revision AUTOMATIC TRANSMISSION 23A-3 GENERAL DESCRIPTION M1231100100125 The automatic transmission comes in one model V5A51. TRANSMISSION The transmission is made up of the torque converter and gear train. A 3-element, 1-step, 2-phase torque con- . ITEM SPECIFICATION Model V5A51 Engine 6G75 (3.8L Engine) Torque converter type With torque converter clutch Transmission type Electronically controlled 5-speed full automatic Control elements Clutch Multiple disc type 4 sets Brake Multiple disc type 2 sets, band type 1 set One-way clutch Sprag type 2 set Gear ratio 1st gear 3.789 2nd gear 2.057 3rd gear 1.421 4th gear 1.000 5th gear 0.731 Reverse gear 3.865 Oil pump type Gear type Oil cooling system Water-cooled type Transfer type Active Track 4WD II Shift ratio High 1.000 Low 1.900 Transmission fluid Specified lubricants DIAMOND ATF SP III Quantity dm 3 (qt) 9.7 (10.2) Transfer oil Specified lubricants Gear oil API classification GL-4 SAE 75W-85W or 75W-90 Quantity dm 3 (qt) 2.8 (3.0) |
