SUNROOF ASSEMBLY TSB Revision BODY 42-67 REMOVAL SERVICE POINTS . <<A>> DRAIN HOSE REMOVAL . <<B>> SUNROOF MOTOR REMOVAL CAUTION Always close the roof lid glass fully before removing the INSTALLATION SERVICE POINTS . >>A<< DRAIN HOSE INSTALLATION drain hose, and wind tape around it until it is smooth. 2. Feed the drain hose through the wheel housing aperture. Pull the code until the drain hose appears, and then untie 3. Install the grommet, and then position the drain hose so that it protrudes from the grommet as shown in the illustration. AV1257AE ACX00574 CORD AB DRAIN HOSE AV1258AE ACX00575 DRAIN HOSE AC CORD ACX00576 A18A0213 GROMMET 20 − 30 mm (0.8 −1.2 in) AC |
